The OxyGuard Polaris C MaxiTemp is a small electronic thermometer specially designed to meet the demands of fish farmers and other professional people for a rugged, reliable and accurate thermometer with data logging function. It has a measuring range of -5 to +45°C with an accuracy of +/- 0.1°, and will measure up to +60°C with an accuracy of +/- 0.2°C. The probe is manufactured in plastic and sea-water resistant stainless steel, and is connected to the display with a 1.5 m cable. Both probe and display are sealed and waterproof.
Values can be stored either automatically at preset time intervals, or manually. You can group values according to the place of measurement. Stored values can be transferred to a PC using the Polaris Link, which connects to the PC via a USB cable.
Standard Service for your OxyGuard Polaris Unit. Standard Service includes
Inspection & Assessment
Replace Membrane, O-Ring and electrolyte
Probe Renovation
Calibration
Certificate of Calibration
UK Shipping of Instrument back to you.
This service is available for;
OxyGuard Polaris
OxyGuard Polaris 2
OxyGuard Polaris C
Note. Any issues/failures identified during service will be quoted for your consideration
OxyGuard temperature probes are robust, accurate and easy to use. They are filled with a special compound that protects against moisture. As standard the probes are fitted with 7 m cable, but they can be supplied with other lengths on request. The sensor in both types of probe consists of a stainless steel cylinder containing the thermistor or Pt100 element. This sensor tip is fitted to a black plastic housing. Standard types of housing are shown overleaf, but others can be supplied on request, e.g. to fit other pipe threads or fittings.
Cobália is an advanced farm management platform that enables you to control and evaluate every part of your production. The farm management system will keep track of daily, monthly and yearly tasks, auto-generate reports for authorities, keep track of inventory and give a complete visual overview of the conditions on your farm.
Optimisation
Management
Price if for a single tag
The Polaris C pH is a hand-held, pocket-size pH hand-held meter designed for use in demanding, wet environments. The meter itself and the electrode assembly are waterproof. This instrument does not suffer from the classical problems associated with pH meters – the Polaris C pH is sealed so that water cannot enter the top of the electrode or the electronics. You can drop it into the water without damaging it. In the Polaris C pH these advantages are combined with microprocessor technology to provide an instrument that is exceptionally easy to use.
Measuring Range: -1 to 15 pH
The Model 420 is a membrane covered galvanic oxygen probe with built-in two-wire 4-20 mA transmitter. The probe is connected to a DC supply and draws a current of between 4 and 20 mA corresponding to the oxygen concentration.
There are only two wires to connect, and there is no limit to cable length. The output signal is galvanically isolated from the built-in electronics and the process fluid. Interference between the Model 420 and other equipment can never occur!
The OxyGuard Model 420 can therefore be connected directly to a wide range of equipment that can accept a 4-20 mA input, such as alarms, indicators, controllers, recorders, PLC’s, PC systems with A/D input etc.
The Model 420 can also be used to measure gaseous oxygen concentration.
D033 OxyGuard Model 420 DO Probe for 4-20mA
The OxyGuard Salinity Probe is specially designed for aquaculture use. Factory calibration and automatic temperature compensation make it very easy to use. It is found in two versions. One is a 3-wire 4-20 mA sensor – connect it to 24 VDC and the output varies between 4 and 20 mA according to the salinity. The other has data bus connection for use with OxyGuard Pacific.
The probe is designed to be as trouble-free as possible, with features specially suited for aquacultural use. Inductive technology is used so that you don’t have to worry about deposits on the surface of the probe – all you have to do is ensure that the hole in the probe is open and relatively clean.
The probe measures salinity according to the internationally agreed PSS-78 scale (Practical Salinity Scale 78).
