Aquafilter FCCA10BB 10" Big Blue combination of NSF approved coconut shell activated carbon and speciality media provides efficient removal of contaminants from potable water. GAC-type cartridges are designed such that where water flows from bottom to top, ensuring long contact time and allowing for maximum adsorption and treatment. Due to the unique formula developed by our R&D Department, the GAC cartridges made by Aquafilter are capable of water softening and scale prevention and reduction in addition to traditional product competencies. They also remove chlorine and organic contaminants, heavy metals from water (i.e. lead, copper, mercury) as well as radioactive particles (cesium, strontium). The cartridges are excellent for taste and odour improvement.Specifications:
Media: NSF approved Coconut Shell GAC, zeolite
Filter Life: 6 -12 months
Size : 10” x 4 1/2
Operating Pressure: 6 bar
Min. feedwater temp. 2°C
Max. feedwater temp. 55°C
Contaminant Removal: Chlorine, VOC's, heavy metals, reduces water hardness
End caps: PP
Gasket: Silicone
Body: HDPE
Post-filter: PP
Aquafilter FCCA20BB 20" Big Blue combination of NSF approved coconut shell activated carbon and speciality media provides efficient removal of contaminants from potable water. GAC-type cartridges are designed such that where water flows from bottom to top, ensuring long contact time and allowing for maximum adsorption and treatment. Due to the unique formula developed by our R&D Department, the GAC cartridges made by Aquafilter are capable of water softening and scale prevention and reduction in addition to traditional product competencies. They also remove chlorine and organic contaminants, heavy metals from water (i.e. lead, copper, mercury) as well as radioactive particles (cesium, strontium). The cartridges are excellent for taste and odour improvement.Specifications:
Media: NSF approved Coconut Shell GAC, zeolite
Filter Life: 6 - 12 months
Size : 20” x 4 1/2”
Operating Pressure: 6 bar
Min. feedwater temp. 2°C
Max. feedwater temp. 55°C
Contaminant Removal: Chlorine, VOC's, heavy metals, reduces water hardness
End caps: PP
Gasket: Silicone
Body: HDPE
Post-filter: PP
AQUAFILTER FCCEL20M10B Big Blue cartridges are manufactured from durable polyester non-woven fabric. They contain no binders or cellulose and have been developed specifically for drinking and bottled water applications. In order to provide increased surface area and longer life, FCCEL20M10B series cartridges are pleated around a polypropylene core. The core gives the cartridges additional strength. The end caps are immersed in a vinyl plastisol which fuses these components together acting as both an endcap and a gasket. FCCEL20M10B series cartridges provide great sediment removal and dirt holding capacity to extend the time between cartridge changeouts. Cartridges are characterized by excellent sediment absorption of sand, silt, rust and suspended solids from potable water. In addition, these filter cartridges effectively protect boilers and pluming systems. Utilizing 100% synthetic media makes FCCEL20M10B series cartridges washable and reusable. If the cartridge becomes clogged you can easily clean it by direct spray into pleats to dislodge sediment or let dry and brush off filter cake from surface of the media. FCCEL20M10B series cartridges are bacteria and chemical resistant. They are characterized with very low pressure drop.FCCEL20M10B series cartridges are typically used as a first stage of potable water filtration.Specifications:
Micron rating: 5
Length: 10"
Outer diameter: 4 1/2"
Inner diameter: 1,1"
Min. feedwater temp. 2°C
Max. feedwater temp. 60°C
Avg. Efficiency: 87%
Aquafilter FCCBHD 10" GAC coconut shell series cartridges have been our most popular carbon cartridges for years. GAC-type cartridges are designed such that water flows from bottom to top, ensuring long contact time, allowing for maximum adsorption and treatment. Utilizing a highly efficient longitudinal flow for greater carbon contact time, FCCBHD is ideal where a long contact time allows for high chlorine as well as other organic reductions. Using a clean, water-washed NSF approved coconut shell activated carbon with a large mesh size, this granular range is primarily a chlorine, taste and odour reduction cartridge with the advantage of a post-filter pad to prevent carbon from being washed out and to avoid blockage if high particulate is present. According to internal laboratory studies cartridgeremoves 99% of free chlorine, 85% of certain pesticides, solvents, aromatic hydrocarbons, fenol, benzen and other organic compounds.Specifications:
Media: FDA and NSF
approved Coconut Shell GAC
Filter Life: up to 6 months
Size : 10” x 2 1/2”
Operating Pressure: 6 bar
Min. feedwater temp. 2°C
Max. feedwater temp. 55°C
Contaminant Removal: Chlorine, VOC's
End caps: PP
Gasket: Silicone
Body: HDPE
Post-filter: PP
Aquafilter FCCBKDF 10" are state-of-the-art multimedia filter cartridges. GAC-type cartridges are designed such that where water flows from bottom to top ensures a long contact time, allowing for maximum adsorption and treatment. Utilizing a highly efficient longitudinal flow for greater carbon contact time, FCCBKDF is ideal where a long contact time allows for high chlorine as well as other organic reductions. Cartridges are filled with water-washed coconut shell activated carbon, KDF-55 and non-woven polypropylene layers. Each layer plays an important role in potable water purification. Coconut shell activated carbon used in filter cartridges removes chlorine, solvents and aromatic hydrocarbons (improves the taste and odor) and compounds, phenol, benzene, and organic substances from water. KDF, utilizing redox reactions, kills or inhibits bacteria growth, converts chlorine to chlorides and removes iron, hydrogen sulfide and heavy metals (lead, arsenic, etc.). Used in combination with Activated Carbon, KDF can significantly extend the life of filter cartridges. Non-woven polypropylene creates a barrier that prevents filtration media from being washed out.Specifications:
Media: Coconut Shell GAC and KDF-55 both NSF approved, PP filter
Filter Life: 6 - 12 months
Size : 10" x 2 1/2"
Operating Pressure: 6 bar
Min. feedwater temp. 2°C
Max. feedwater temp. 55°C
Contaminant Removal: Chlorine, VOC's, heavy metals, ferrous iron, hydrogen sulphide, scale
End caps: PP
Gasket: Silicone
Body: HDPE
Post-filter: PP
Aquafilter FCPP20M20B Big Blue series cartridges are made of FDA-approved polypropylene string wound on a polypropylene core which strenghtens the cartridge. It has a broad chemical compatibility, good temperature resistance and low cost. FCPP20M20B series cartridges are primarily used as the first stage of filtration of cold potable water. Cartridges are characterized by excellent sediment absorption of sand, silt, rust and suspended solids from potable water. In addition, these filter cartridges effectively protect expensive home appliances and residential pluming systems.Specifications:
Filter media: PP
Filter Life: 6-12 months
Core: PP or PET
Nominal micron rating: 20
Min. feedwater temp. 2°C
Max. feedwater temp. 65°C
Lengths: 20
Outer diameter: 4 1/2”
Inner diameter: 1,1”
Avg. Efficiency: 90%
Pentek EP Series Carbon Block Cartridges are manufactured using a process that yields a cartridge with a nominal 5-micron filtration rating and high dirt-holding capacity. A high porosity design helps prevent the cartridge from plugging before its adsorption capacity is exhausted, maximizing the utilization of the carbon while maintaining low pressure drop.These cartridges are protected by a uniquely formulated polyolefin bilaminate pre-filter, designed to significantly increase the useful life of the cartridge by trapping sediment that typically plugs carbon block cartridges.EP Series Cartridges make an ideal choice for a wide range of residential, food service, commercial and industrial applications.Features & Benefits
High dirt-holding capacity maximizes utilization of the carbon block
Highly effective bad taste & odour and chlorine taste & odour reduction
Nominal 5-micron rating
Specifications
Filter Media – Bonded PAC
Endcaps – Polypropylene
Outer Wrap – Polyolefin
Netting – Polyethylene
Gaskets – Buna-N
Temperature Rating – 40-180°F (4.4-82.2°C)
Aquafilter FCCBKDF20BB 20" Big Blue are state-of-the-art multimedia filter cartridges. GAC-type cartridges are designed such that where water flows from bottom to top ensures a long contact time, allowing for maximum adsorption and treatment. Utilizing a highly efficient longitudinal flow for greater carbon contact time, FCCBKDF20BB is ideal where a long contact time allows for high chlorine as well as other organic reductions. Cartridges are filled with water-washed coconut shell activated carbon, KDF-55 and non-woven polypropylene layers. Each layer plays an important role in potable water purification. Coconut shell activated carbon used in filter cartridges removes chlorine, solvents and aromatic hydrocarbons (improves the taste and odour) and compounds, phenol, benzene, and organic substances from water. KDF, utilizing redox reactions, kills or inhibits bacteria growth, converts chlorine to chlorides and removes iron, hydrogen sulfide and heavy metals (lead, arsenic, etc.). Used in combination with Activated Carbon, KDF can significantly extend the life of filter cartridges. Non-woven polypropylene creates a barrier that prevents filtration media from being washed out.Specifications:
Media: Coconut Shell GAC and KDF-55 both NSF approved, PP filter
Filter Life: 6 - 12 months
Size : 20" x 4 1/2"
Operating Pressure: 6 bar
Min. feedwater temp. 2°C
Max. feedwater temp. 55°C
Contaminant Removal: Chlorine, VOC's, heavy metals, ferrous iron, hydrogen sulphide, scale
End caps: PP
Gasket: Silicone
Body: HDPE
Post-filter: PP
Aquafilter FCCBKDF10BB 10" Big Blue are state-of-the-art multimedia filter cartridges. GAC-type cartridges are designed such that where water flows from bottom to top ensures a long contact time, allowing for maximum adsorption and treatment. Utilizing a highly efficient longitudinal flow for greater carbon contact time, FCCBKDF10BB is ideal where a long contact time allows for high chlorine as well as other organic reductions. Cartridges are filled with water-washed coconut shell activated carbon, KDF-55 and non-woven polypropylene layers. Each layer plays an important role in potable water purification. Coconut shell activated carbon used in filter cartridges removes chlorine, solvents and aromatic hydrocarbons (improves the taste and odor) and compounds, phenol, benzene, and organic substances from water. KDF, utilizing redox reactions, kills or inhibits bacteria growth, converts chlorine to chlorides and removes iron, hydrogen sulfide and heavy metals (lead, arsenic, etc.). Used in combination with Activated Carbon, KDF can significantly extend the life of filter cartridges. Non-woven polypropylene creates a barrier that prevents filtration media from being washed out.Specifications:
Media: Coconut Shell GAC and KDF-55 both NSF approved, PP filter
Filter Life: 6 - 12 months
Size : 10" x 4 1/2"
Operating Pressure: 6 bar
Min. feedwater temp. 2°C
Max. feedwater temp. 55°C
Contaminant Removal: Chlorine, VOC's, heavy metals, ferrous iron, hydrogen sulphide, scale
End caps: PP
Gasket: Silicone
Body: HDPE
Post-filter: PP
Protect your home, health, and appliances by filtering your water. The ACC-2 Aquafilter Granular Activated Carbon Filter removes major contaminants from your water supply and provides clean water for drinking, showering, cooking, and other home uses. The GAC removes major water contaminants like Chlorine, Total Organic Carbon (TOC), Pharmaceuticals, Turbidity, Volatile Organic Chemicals (VOC), Herbicides, Industrial Solvents, Insecticides, Pesticides, and Chemicals causing bad tastes, odours, and more. The UDF type filter is vacuum sealed and complete with a polypropylene shell, a thermal bonded cap, and an industrial sealed silicon ring to make sure its durable and reliable. Filter your water with high quality coconut carbon for maximum chemical absorption. Choose the filter that lasts longer to give you the best value in filtration.
Aquafilter offers AICRO-AB In-line Granular carbon cartridge with antimicrobial agent suitable for POU (Point of Use) installations. Through its granular activated carbon (GAC) media, AICRO-AB significantly reduces the concentration of chlorine, heavy metals such as, copper, lead, mercury, as well as VOC’s, improving the taste and odour of your drinking water. Additionally, AICRO-AB is provided with nano silver BACINIXTM, an antimicrobial agent which confers protection against bacteria and viruses, ensuring a continuous supply of fresh and clean drinking water.
Protect your home, health, and appliances by filtering your water. The ACC-2 Aquafilter Granular Activated Carbon Filter removes major contaminants from your water supply and provides clean water for drinking, showering, cooking, and other home uses. The GAC removes major water contaminants like Chlorine, Total Organic Carbon (TOC), Pharmaceuticals, Turbidity, Volatile Organic Chemicals (VOC), Herbicides, Industrial Solvents, Insecticides, Pesticides, and Chemicals causing bad tastes, odors, and more. The UDF type filter is vacuum sealed and complete with a polypropylene shell, a thermal bonded cap, and an industrial sealed silicon ring to make sure its durable and reliable. Filter your water with high quality coconut carbon for maximum chemical absorption. Choose the filter that lasts longer to give you the best value in filtration.
2" x 10" in-line cartridge with coconut shell granulated activated carbon (GAC). It is mostly used for RO systems in order to improve the taste and aroma of filtered water. It can also be installed in "SIDE-BY-SIDE" type refrigerators to reduce chlorine, organic substances and certain pesticides. Available sizes: 2" x 10"
Aquafilter FCPS20-L 20" series cartridges are NSF certified using FDA approved polypropylene for material requirements. The construction of this pure polypropylene, surfactant-free depth filter ensures low pressure drops, with exceptional dirt holding capabilities. FCPS20-L uses no resin binders, lubricants, antistatic or release agents or other chemical additives. The one-step manufacturing process continuously extrudes and thermally bonds pure polypropylene microfibres into a complex filter matrix. Cartridges are characterized by excellent sediment absorption of sand, silt, rust and suspended solids from potable water. Polypropylene fibers are chemical resistant and prevent development of microorganisms. In addition, these filter cartridges effectively protect expensive home appliances and residential pluming systems. FCPS2-L series cartridges are an ideal true depth filters and can be used for filtration of cold potable water. Aquafilter wide range of melt-blown cartridges has multiple fiber zones. These multi-fibre zones provide a graded pore structure throughout the filter’s depth. Our filter cartridges have been designed to capture and retain contaminants throughout the entire cross section of the filter. The multiple fibre zones give our filter cartridges a major competitive advantage over other melt-blown filters with fewer pore size gradients in their structure. Aquafilter melt-blown filters demonstrate true graded depth filtration, the results are long filter service life, therefore lower consumable costs. The new, modern, automatic manufacturing equipment used to produce our wide range of melt-blown cartridge filters delivers consistently efficient filters at low costs.Specifications:Filter media: PPFilter life: up to 6 monthsMin. feedwater temp. 2°CMax. feedwater temp. 80°CNominal micron rating: 20Lengths: 20"Outer diameter: 2 1/2”Inner diameter: 1.1”Avg. Efficiency: 90%
