Pentek EP Series Carbon Block Cartridges are manufactured using a process that yields a cartridge with a nominal 5-micron filtration rating and high dirt-holding capacity. A high porosity design helps prevent the cartridge from plugging before its adsorption capacity is exhausted, maximizing the utilization of the carbon while maintaining low pressure drop.These cartridges are protected by a uniquely formulated polyolefin bilaminate pre-filter, designed to significantly increase the useful life of the cartridge by trapping sediment that typically plugs carbon block cartridges.EP Series Cartridges make an ideal choice for a wide range of residential, food service, commercial and industrial applications.Features & Benefits
High dirt-holding capacity maximizes utilization of the carbon block
Highly effective bad taste & odour and chlorine taste & odour reduction
Nominal 5-micron rating
Specifications
Filter Media – Bonded PAC
Endcaps – Polypropylene
Outer Wrap – Polyolefin
Netting – Polyethylene
Gaskets – Buna-N
Temperature Rating – 40-180°F (4.4-82.2°C)
Pentek EP Series Carbon Block Cartridges are manufactured using a process that yields a cartridge with a nominal 5-micron filtration rating and high dirt-holding capacity. A high porosity design helps prevent the cartridge from plugging before its adsorption capacity is exhausted, maximizing the utilization of the carbon while maintaining low pressure drop.These cartridges are protected by a uniquely formulated polyolefin bilaminate pre-filter, designed to significantly increase the useful life of the cartridge by trapping sediment that typically plugs carbon block cartridges.EP Series Cartridges make an ideal choice for a wide range of residential, food service, commercial and industrial applications.Features & Benefits
High dirt-holding capacity maximizes utilization of the carbon block
Highly effective bad taste & odour and chlorine taste & odour reduction
Nominal 5-micron rating
Specifications
Filter Media – Bonded PAC
Endcaps – Polypropylene
Outer Wrap – Polyolefin
Netting – Polyethylene
Gaskets – Buna-N
Temperature Rating – 40-180°F (4.4-82.2°C)
EP-10, EP-20, EP-30, EP-40, EP-20, EP-10, EP-30, EP-40
EPM Series cartridges are a modified version of our EP Series cartridge. An economical price makes this cartridge an attractive choice for taste, odour, and chlorine taste & odour reduction, as well as sediment filtration.EPM Series cartridges have a nominal 10-micron filtration rating, high porosity and chlorine taste & odour reduction. The high porosity design helps prevent the cartridge from plugging before its adsorption capability is exhausted, maximizing the utilization of the carbon while maintaining low pressure drop.These cartridges are protected by an outer wrap designed to significantly increase the useful life of the cartridge by trapping sediment that typically plugs carbon block cartridges.Features & Benefits
Nominal 10-micron rating
Enhanced dirt holding capacity for extended cartridge life
Lowest pressure drop
Bad taste & odour and chlorine taste & odour reduction
Economically priced
Specifications
Filter Media – Bonded PAC
Endcaps – Polypropylene
Outer Wrap – Polyolefin
Netting – Polyethylene
Gaskets – Buna-N
Temperature Rating – 40-180°F (4.4-82.2°C)
EPM Series cartridges are a modified version of our EP Series cartridge. An economical price makes this cartridge an attractive choice for taste, odor, and chlorine taste & odor reduction, as well as sediment filtration.EPM Series cartridges have a nominal 10-micron filtration rating, high porosity and chlorine taste & odor reduction. The high porosity design helps prevent the cartridge from plugging before its adsorption capability is exhausted, maximizing the utilization of the carbon while maintaining low pressure drop.These cartridges are protected by an outer wrap designed to significantly increase the useful life of the cartridge by trapping sediment that typically plugs carbon block cartridges.Features & Benefits
Nominal 10-micron rating
Enhanced dirt holding capacity for extended cartridge life
Lowest pressure drop
Bad taste & odour and chlorine taste & odour reduction
Economically priced
Specifications
Filter Media – Bonded PAC
Endcaps – Polypropylene
Outer Wrap – Polyolefin
Netting – Polyethylene
Gaskets – Buna-N
Temperature Rating – 40-180°F (4.4-82.2°C)
Suitable for the polishing of trace hydrocarbons, the OilOut-99 is capable of absorbing up to three times its own weight before changeout is required. Designed to remove up to 99% of dispersed hydrocarbons, the SPECTRUM SRIF is suited to applications where the inlet contamination is below 500mg/l, such as surface run off water, CNC machine coolant and bilge separators. The OilOut-99 achieves best results as a polishing phase after primary oil removal technologies or in a double-pass system and is effective at removing a range of contaminants, including mineral oils and BTEX hydrocarbons.
Suitable for the polishing of trace hydrocarbons, the OilOut-99 is capable of absorbing up to three times its own weight before changeout is required. Designed to remove up to 99% of dispersed hydrocarbons, the SPECTRUM SRIF is suited to applications where the inlet contamination is below 500mg/l, such as surface run off water, CNC machine coolant and bilge separators. The OilOut-99 achieves best results as a polishing phase after primary oil removal technologies or in a double-pass system and is effective at removing a range of contaminants, including mineral oils and BTEX hydrocarbons.
Suitable for the polishing of trace hydrocarbons, the OilOut-99 is capable of absorbing up to three times its own weight before changeout is required. Designed to remove up to 99% of dispersed hydrocarbons, the SPECTRUM SRIF is suited to applications where the inlet contamination is below 500mg/l, such as surface run off water, CNC machine coolant and bilge separators. The OilOut-99 achieves best results as a polishing phase after primary oil removal technologies or in a double-pass system and is effective at removing a range of contaminants, including mineral oils and BTEX hydrocarbons.
Suitable for the polishing of trace hydrocarbons, the OilOut-99 is capable of absorbing up to three times its own weight before changeout is required. Designed to remove up to 99% of dispersed hydrocarbons, the SPECTRUM SRIF is suited to applications where the inlet contamination is below 500mg/l, such as surface run off water, CNC machine coolant and bilge separators. The OilOut-99 achieves best results as a polishing phase after primary oil removal technologies or in a double-pass system and is effective at removing a range of contaminants, including mineral oils and BTEX hydrocarbons.
Absorbing three times its own weight before changeout is required, the OilOut-99 range can remove up to 99% of hydrocarbons. Principally designed for the efficient removal of dissolved and dispersed hydrocarbons from water, the SPECTRUM SRIF offers a compact solution to typically difficult and costly applications. Using a patented formula, the cartridges can absorb up to three times their own weight before exhaustion and with the engineered design of the cartridge, even when the cartridge is at capacity, no hydrocarbons are released from the media into the water supply downstream. With a range of lengths and sizes available to suit a variety of existing filter housings, the SRIF provides effective hydrocarbon removal at high flowrates while maintaining low pressure differential. Each pass through an OilOut can remove up to 99% of dissolved and dispersed hydrocarbons, with each standard diameter 10” cartridge capable of absorbing up to 360g of hydrocarbons and each large diameter 10” cartridge capable of removing 1290g
Product FeaturesEffectively removes through absorption dissolved and dispersed hydrocarbons efficiently from water, absorbing three times its own weight before changeout is required As the cartridge becomes exhausted, flow is not affected and no hydrocarbons are released Removes up to 99% of hydrocarbons with each 10" cartridge having a capacity of 360g in standard size and 1290g in its large diameter format Constructed from resin impregnated felt, polypropylene core and end caps, protected by polyethylene netting Multiple end cap options in standard and large diameter configurations ensures the OilOut-99 is suitable for large scale industrial to small commercial applications
Applications and IndustriesBilge water Trace oil Surface water Degreasing Industrial discharge water
Box Quantities10" x 2.5" - 15pcs 20" x 2.5" - 7pcs 30" x 2.5" - 9pcs 40" x 2.5" - 9pcs 10" x 4.5" Large Diameter - 4pcs 20" x 4.5" Large
Developed as the direct replacement to the Pentair C1, the SPECTRUM SCW is adept at removing high levels of sediment and contaminants. Employing traditional carbon wrap technology to reduce odours, remove chlorine, water pigmentation and other volatile organic compounds, the SCW combines the advantages of a high-dirt loading depth cartridge and adsorption capabilities of granular activated carbon; an ideal combination to treat drinking water.
Developed as the direct replacement to the Pentair C1, the SPECTRUM SCW is adept at removing high levels of sediment and contaminants. Employing traditional carbon wrap technology to reduce odours, remove chlorine, water pigmentation and other volatile organic compounds, the SCW combines the advantages of a high-dirt loading depth cartridge and adsorption capabilities of granular activated carbon; an ideal combination to treat drinking water.
Developed as the direct replacement to the Pentair C1, the SPECTRUM SCW is adept at removing high levels of sediment and contaminants. Employing traditional carbon wrap technology to reduce odours, remove chlorine, water pigmentation and other volatile organic compounds, the SCW combines the advantages of a high-dirt loading depth cartridge and adsorption capabilities of granular activated carbon; an ideal combination to treat drinking water.
