Description
Pentair Big Clear Filter Housings offer the versatility to meet all of your large capacity filtration needs, including high-flow and heavy-sediment applications. The extra large housing allows for greater cartridge capacity, reducing the number of vessels required for high flow-rate applications. Sumps are available in both 10" and 20" lengths.
Big Clear Filter Housings offer on-site examination of flow, performance, and cartridge life and are ideal for a variety of applications. The 1" polypropylene caps are available with a pressure-relief button on the inlet side to relieve pressure inside the housing and are available in 10" and 20" lengths.
Caps are constructed of reinforced polypropylene. The 10" sumps are made of Lexan® and the 20" sumps are SAN (Styrene acrylonitrile)
Features, Options, & Benefits
- Large capacity housing suitable for high flow applications
- Available in 10" and 20" lengths
- Pressure relief/bleed on inlet side of cap
- Accepts 4-1/2" diameter cartridges
Specifications
- Housing - Styrene Acrylonitrile (clear)
- Cap - Reinforced polypropylene
- Button Assembly - 300-Series stainless-steel, EPDM, and polypropylene
- Maximum Temperature - 38°C
•Maximum Pressure - 10": 6.9 bar, 20" 6.2 bar
Specifications
- Brand: Pentair
- Port Size: 1"
- End-Cap: AA / DOE
- Max Pressure (bar): 6.2
- Temp. Rating (°C): 37.8
- Material: Polypropylene
- Configuration: 1 Cartridge (20" x 4.5")
- Flow Rate (lpm): 90
