The Mimosoa N5-45x2 Sector Antenna is the industry’s first sector antenna to deliver the best of both worlds — incredible noise rejection and long-distance performance, with wideband 4.9–6.4 GHz operation for fixed wireless broadband. The dual-slant polarization, 45º sector can be used with any third-party 2x2 MIMO radio solution, or two N5-45x2 antennas can be connected to the 4x4 MIMO Mimosa A5c access point, aimed in different directions, for 2x spectrum reuse, superior range and noise rejection at collocation and tower sites.
Key Features
Industry-Leading Front-to-Back Ratio for 2x Spectrum Reuse
World-Class Noise Rejection
High-Gain for Long Distances
Wideband 4.9–6.4 GHz Sector
Reject Noise and Synchronise
Overcoming noise at tower sites is key to scaling capacity. The N5-45x2 delivers industry-leading side lobe rejection and an unprecedented 43 dB front-to-back (FTB) performance — the highest FTB ratio of any sector or horn antenna in the industry. Compatible with any third-party, 2x2 MIMO radio solution, there’s no higher performance antenna in the industry.
Wideband Operation
Supporting 4.9 GHz public safety applications and multipoint licensed operation up to 6.4 GHz, where regulations allow, the N5-45x2 provides an additional 800 MHz of spectrum beyond the crowded 5.15–5.85 GHz unlicensed channels.
Go the distance
The Mimosa N5-45x2 offers the best of both worlds — a long distance, high gain sector with the superior noise isolation of a horn. Competitive sectors offer high-gain, but fail to reduce side lobe and front-toback noise. Symmetric horn antennas achieve good noise isolation, but typically offer lower gain and inefficient symmetrical ground coverage patterns.
Compatible with Third-Party Radios
Blending the best of sector antennas with the best features of a horn, the Mimosa N5-45x2 is a great sector antenna choice to use with any 2x2 MIMO radio. Even better, the ultra-wide 9º vertical beamwidth covers substantially more ground than other leading sector antennas.
Product Features:
Industry-Leading Front-to-Back Ratio for 2x Spectrum Reuse
World-Class Noise Rejection
High-Gain for Long Distances
Wide-band 4.9GHz – 6.4GHz Sector
Antenna Specifications:
Gain: 19dBi
Polarization: Slant 45°
Azimuth Beamwidth (3 dB): 42°
Elevation Beamwidth (3 db): 9°
Electrical Downtilt: 2°
Front-to-Back Ratio (min): 43dB
Cross-Polar Isolation: >30dB
Port-to-Port Isolation: >10dB
Impedance: 50 Ω
Max Input Power: 30dBm
Physical Specifications:
Dimensions: Height: 427mm (16.81”) Width: 143mm (6.63”) Depth: 76mm (3.0”) including connectors
Shipping Box Dimensions: Height: 662mm (26.06”) Width: 166mm (6.53”) Length: 100mm (3.94”)
Weight: 2.81kg (6.2lbs)
RF Connectors: 2 N-type female (includes two 1 meter LMR 240 Type-N to Type-N cables)
RF Connectors Position: Back of antenna, near center
Enclosure Characteristics: Outdoor, UV stabilized, engineered polymer
Mounting: Galvanized steel, dual attached pole mount with 20° mechanical up or down tilt. Two mounting brackets included. For pole sizes, maximum is 3.5” (90 mm) and minimum is 1.5” (38 mm).
Wind Survivability: 200 km/h (125 mph)
Wind Loading: 4.77 kg @ 160 km/h (10.49lbs @ 100 mph)
Environmental:
Outdoor Ingress Protection Rating: IP55
Operating Temperature: -40°C to +55°C (-40°F to 131°F)
Operating Humidity: 5 to 100% condensing
Operating Altitude: 4,420 m (14,500’) max
Shock & Vibration: ETS 300-019-2-4 class 4M5
RoHS Compliance: Yes
Product Includes:(1) N5-45x2 Sector Antenna(1) User Manual(2) Mounting Brackets
The Mimosa B5x is one of the industry’s fastest unlicensed, point-to-point (PTP), backhaul solutions. It’s ideal for short to medium range relay and tower links, custom-engineered collocation, and licensed 4.9 GHz spectrum. It’s modular, with the ability to connect X-series compatible twist-on antennas (12 dBi horn, 16 dBi horn, 20 dBi dish, 25 dBi dish).
Mimosa B5x Key Features
Wide Frequency Range
Beamforming Technology
Optimised 360º Performance
Fast and Flexible
As one of the highest capacity, unlicensed PTP solutions in the industry, it delivers up to 1.5 Gbps (IP). 160 MHz of aggregate channel capacity and GPS Sync mode provide flexibility for performance.
Double Reliability
Tame unlicensed spectrum interference via custom-engineered multi-channel and auto-everything technology—as good as two smart links in one radio.
Extended Frequency
Rise above the noise with extended frequency support from 4.9–6.4 GHz.
Ultra Rugged
Carrier-grade IP67 design allows the B5x to withstand the harshest of environmental conditions.
Easily Add New Links
The B5x is spectrum friendly. Unique, high-precision GPS Sync technology reuses the same channel network wide. Keep adding more capacity to more sites and waste less spectrum.
Monitor With Ease
Assessing link health and identifying potential problems has never been easier. Links are instantly monitored from the Mimosa management platform.
Product Features:
As one of the highest capacity, unlicensed PTP solutions in the industry, it delivers up to 1.5Gbps (IP). 160MHz of aggregate channel capacity and GPS Sync mode provide flexibility for performance.
Tame unlicensed spectrum interference via custom-engineered multi-channel and auto-everything technology—as good as two smart links in one radio.
Rise above the noise with extended frequency support from 4.9GHz – 6.4GHz.
Carrier-grade IP67 design allows the B5x to withstand the harshest of environmental conditions.
The B5x is spectrum friendly. Unique, high-precision GPS Sync technology reuses the same channel network wide. Keep adding more capacity to more sites and waste less spectrum.
Assessing link health and identifying potential problems has never been easier. Links are instantly monitored from the Mimosa management platform.
Product Specifications:
Max Throughput: Up to 1.5Gbps IP aggregate UL/DL (1.7Gbps PHY)
Latency: <1ms in auto mode
Wireless Protocols: Fixed TDMA and TDMA-FD (Frequency Diversity) with 75:25,m67:33, or 50:50 traffic ratios with 2, 4, or 8ms timeslots; Auto-TDMA
MIMO & Modulation: 4x4:4 MIMO OFDM up to 256QAM
Bandwidth: Single or dual 20/40/80 MHz channels
Frequency Range: 4.90GHz – 6.40GHz; Restricted by country of operation
Max Output Power: 30dBm (1x mode, i.e. single frequency) 27dBm (2x mode, i.e. dual frequency)
Sensitivity (MCS 0): -87dBm @ 80MHz -90dBm @ 40MHz -93dBm @ 20MHz
Integrated Antenna Gain: 8dBi
Max Power Consumption: 20W
System Power Method: 48VDC 802.3at (PoE+) active or passive compliant power injectors
System Lightning & ESD Protection: 6kV
Recommended Power Supply: (not included): 50 VDC passive Gigabit PoE injector
Operating Temperature: -40°C to +55°C (-40°F to 131°F)
Dual Link Operation: 2 independent dual-stream radios operating on non-contiguous frequencies; Automatic load balancing of traffic across 4 total MIMO streams with individual stream encoding up to 256 QAM
Management Services: Mimosa management; SNMPv2 & Syslog legacy monitoring; HTTPS; HTML 5 based Web UI
Smart Spectrum Management: Active scan monitors/logs ongoing RF interference across channels (no service impact); Dynamic auto-optimization of channel and bandwidth use
Security: 128-bit AES PSK with hardware acceleration
QoS: 4 classes of QoS, with user configurable priority queuing, weighted fair queuing, MIR, CIR, and rate limiting
Collocation Synchronization: 1PPS GPS TX/RX synchronization for collocated cochannel radios; Adjustable up/downstream bandwidth ratio
Regulatory and Compliance: FCC Part 15.407, IC RSS210, CE, ETSI 301 893/302 502
RoHS Compliance: Yes
Safety: EN 62638-1, CAN/CSA C22.2 No. 62368-1
Product Includes:
(1) Mimosa B5x PTP Backhaul Radio (100-00109)
TheKSF coupling set (6") for connecting flexible hoses. The hose connection is easily attached by means of Ksf quick lock 6".
Manufactured in stainless steel 304.
The Model 420 is a membrane covered galvanic oxygen probe with built-in two-wire 4-20 mA transmitter. The probe is connected to a DC supply and draws a current of between 4 and 20 mA corresponding to the oxygen concentration.
There are only two wires to connect, and there is no limit to cable length. The output signal is galvanically isolated from the built-in electronics and the process fluid. Interference between the Model 420 and other equipment can never occur!
The OxyGuard Model 420 can therefore be connected directly to a wide range of equipment that can accept a 4-20 mA input, such as alarms, indicators, controllers, recorders, PLC’s, PC systems with A/D input etc.
The Model 420 can also be used to measure gaseous oxygen concentration.
D033 OxyGuard Model 420 DO Probe for 4-20mA
YSI ODO replacement optical dissolved oxygen screw-on sensor cap.
Overview
Includes screw-on sensor cap and calibration code sequence.
Average life is 1 year or greater.
Response Time (T95 - from 0 to 100%) = 40 seconds Flow Dependence After 4 Minutes = 0% Required Flow Rate = 0 inches/second; non-consumptive optical method
Specifications
Equipment used with
ProODO Probe
YSI 2002 Galvanic Dissolved Oxygen sensor for the Pro Series
OverviewEasy user-replaceble sensor allows for quick sensor replacements if needed. No tools necessary. The 2002 Galvanic Dissolved Oxygen sensor comes with 5913 Cap Membrane Kit (1.25 Mil PE, Polyethylene membranes) for fast response with reliable readings. Convenient screw-on cap membranes make membrane changes simple and easy. Six-month sensor warranty.
CompatibilityThe 2002 Galvanic DO Sensor is compatible with these YSI Handheld Instruments*: • ProQuatro • Pro Plus • Pro20 • Pro20i • Pro1020 • Pro2030 *Requires Cable/Probe Assembly.
For use in the PBH plastic bag housings, this range of bags proves a simple and economic solution for the removal of particulate. PBH bags are uniquein design, fitting in an internal support basket to maximise the filtration surface area and are easy for operators to changeout. Available in washable nylon mesh in 50 to 600 micron and in polypropylene felt in 1 to 200 micron.BN Series (Strainer)
Woven monofilment materials are offered in nylon with micron ratings of 50 to 800
Efficiencies from 75 to 95 percent
Materials are cleanable and reusable
Features and Benefits
Semi-rigid cylindrical design is easily crushed and incinerated
For use with Pentair Pentek PBH-410 Housing
Higher productivity – faster bag “change-outs”
Thermally welded unique design results in consistent filtration efficiencies
Nominal 1-800 micron ratings
The exclusive use of internationally recognised high-performance compressors and of the titanium coaxial heat exchanger, ensures high performances. The set of technologies used allows you to decrease noise levels and achieve the highest COP-Coefficient Of Performance, contributing to significant energy savings.
Digital Thermostat
The setting of functions is intuitive and the temperature reading is accurate, resolution 0,1°C/1°F. The setting range is 5°C - 30°C (41°F - 86°F) and the temperature is kept constant with a maximum differential of 0,5 °C/0,5 °F. Displayed temperatures are in ° C or ° F and there are security alarms.
Efficient Design
The chiller, with its innovative design, is characterized by a solid structure designed to guarantee a perfect protection against rust. The user will appreciate the functionality of the shape and the compact size, which makes the chiller ideal also for confined spaces.
Unique Features
The “TECObody-condenser system” represents another major achievement: besides performing its main function as an integral part of the structure, the condenser confers an exclusive and original design to the chiller. Moreover, it makes the use of the filter unnecessary, thus eliminating the cleaning problems normally associated with it. The heater cannot be installed in this model.
Power supply
Water temp.
Liters
US Gallons
COP**
50Hz
25° C*
150
40
1,19
*The values reported in the table refer to the following conditions: room temp. 30°C, heating load of 0.5 w/lt. **Coefficient of performance
Power Supply
Power Consumption
Gas
Weight
Ambient temperature
50Hz
210 W
R134
26,9 lb
10°C - 38°C
All data are approximate and may be changed without notice by TECO.
Technical Details
Supply
230V-50Hz
Cooling Power Consumption
150 w
Ecological Gas
R134a
Min. Flow Rate
400 l/h
Tank Size
up to 150 l (water temp. 25°C - Room temp. 30°C - Heating load 0.5 w/l)
Dimensions (millimeters)
215 (w) x 361 (d) x 315 (h)
Dimensions (inches)
8.46 (w) x 14.21 (d) x 12.4 (h)
Connections
fitting 1/2" - 12mm int. tube diameter
Where long life, high purity and low change-outs are required, the Purtrex range meets the requirements of most non-critical applications or as an economic pre-filter.The patented construction of this pure polypropylene, surfactant-free depth filter ensures low pressure drops, with exceptional dirt holding capabilities in standard as well as large diameter options, making it the next generation replacement product to wound and wrongly specified resin-bonded cartridges.Containing no anti-static wetting agents, solvents or binders the Purtrex’s one-step manufacturing process continuously extrudes and thermally bonds pure polypropylene microfibers into a complex filter matrix. Micro-filaments plus precise fibre control maximizes the positive filtration characteristics of the graded density, tight cut-offs and maximum void areas with millions of tortuous paths.Material of Construction
Filtration Media: Polypropylene
End caps and Adapters: Polypropylene
Dimensions
Nominal Outside Diameter: 2.50 inch (6.4 cm)
Nominal Inside Diameter: 1 inch (2.5 cm)
Operating Limits
Maximum Differential Pressure:35psi (2.4bar) at =100°F (38°C)
Maximum Temperature: 160°F (71°C) at =15psid (1.0bar)
Recommended Maximum Water Flow: 5 gpm (19L/min) per 10-inch length
Where long life, high purity and low change-outs are required, the Purtrex range meets the requirements of most non-critical applications or as an economic pre-filter.The patented construction of this pure polypropylene, surfactant-free depth filter ensures low pressure drops, with exceptional dirt holding capabilities in standard as well as large diameter options, making it the next generation replacement product to wound and wrongly specified resin-bonded cartridges.Containing no anti-static wetting agents, solvents or binders the Purtrex’s one-step manufacturing process continuously extrudes and thermally bonds pure polypropylene microfibers into a complex filter matrix. Micro-filaments plus precise fibre control maximizes the positive filtration characteristics of the graded density, tight cut-offs and maximum void areas with millions of tortuous paths.Material of Construction
Filtration Media: Polypropylene
End caps and Adapters: Polypropylene
Dimensions
Nominal Outside Diameter: 2.50 inch (6.4 cm)
Nominal Inside Diameter: 1 inch (2.5 cm)
Operating Limits
Maximum Differential Pressure:35psi (2.4bar) at =100°F (38°C)
Maximum Temperature: 160°F (71°C) at =15psid (1.0bar)
Recommended Maximum Water Flow: 5 gpm (19L/min) per 10-inch length
The AISTRO-2 is an In-line water softening cartridge with clear housing. Exchanges calcium and magnesium with sodium ions and therefore reduces water hardness. Available with 1/4″ NPT connection.
The AISTRO-2 utilizes FDA-grade sodium based strongly acidic ion-exchange resin which reduces calcium and magnesium ions content in water. Calcium and magnesium are often called “hardness minerals”. Large amount of these ions in water are responsible for a formation of the scale deposits, higher detergent consumption and stains on a glassware. In extreme situations large amount of calcium and magnesium can lead to glass etching. Hard water leaves an invisible film on a skin, which blocks pores. This in turns causes chapping, itching and dryness. Softened water contains almost no calcium & magnesium. It enables people to use lesser quantities of soap, shampoo, and skin care products. Moreover detergent consumption is reduced. Available size: 2,5″ x 12″ Working temperature: 2°C – 45°C Longevity: 3 – 6 months (depending on feed water quality).
Applications / Uses– pre RO systems – under sink – icemakers – water coolers – refrigerators – coffee makers – and other application Keep in mind when water is extremely hard, filter will be exhausted very quickly, therefore a conventional water softener should be used.
Technical Specification
Media: FDA approved ion exchange resin Connections: 1/4″ NPT Filter Life: 3 – 6 months Dimensions: 2,5″ x 12″ (74 mm x 288 mm) Flow Rate: 2.8 l/min (0.75 gpm) Operating Pressure: 6 bar (90 psi) Minimum Temperature: 2°C (35°F) Maximum Temperature: 40°C (104°F) Body & Cap: PET Excellent choice for lime scale removal and lime scale problems Made in the EU with High Quality materials
ACR-1 series utilizes FDA-grade, sodium, based, strongly acidic ion-exchange resin which reduces calcium and magnesium ion content in water. Calcium and magnesium are often called "hardness minerals". Large amounts of these ions in water are responsible for the formation of scale deposits, higher detergent consumption and stains on glassware. In extreme cases large amounts of calcium and magnesium can lead to glass etching. Hard water damages home appliances such as: dishwashers and washing machines, and increases their energy consumption.
Aquafilter offers AISTRO In-line Softener cartridge (AISTRO, AISTRO-L-AQ and AISTRO-QC) suitable for POU (Point of Use) installations. Through its double media consisted of ion exchange-based resins, AISTRO cartridges effectively reduce water hardness (high concentration of calcium and magnesium ions). In case your feed water contains a high concentration of suspended matter, AISTRO is commonly preceded by a Sediment filter to avoid a detriment of the cartridge performance. AISTRO fits most 1/4” water lines and requires no additional tools for its installation.
The Ecosoft Big Blue 4.5"x20" in-line filter housing offers extended filtration performance. Perfect for large households or industrial pre-treatment setups using standard 20" cartridges.
High-volume filter housing
Compatible with 4.5"x20" cartridges
Designed for high flow applications
1" threaded ports with mounting bracket
Simplify the upkeep of your water filtration system with the PRBUTTON: PENTAIR Pressure Release Button Kit, an essential spare part designed for seamless compatibility with Pentair 2G housings. This pressure release button plays a crucial role in maintaining system performance and ensuring safe, hassle-free filter maintenance.
Key Features & Benefits
Perfect Compatibility: Specifically designed as a spare part for Pentair 2G housings, ensuring an exact fit for reliable performance.
Pressure Management: The pressure release button allows you to safely release pressure within the housing, making filter changes quick and stress-free.
Ease of Use: Simple to install and operate, it’s a practical addition for both routine maintenance and unexpected repairs.
System Protection: Helps maintain the integrity of your filtration system, extending its lifespan by promoting safe maintenance practices.
The PRBUTTON: PENTAIR Pressure Release Button Kit is a small yet vital component that supports the efficiency and longevity of your water filter housing.
The SPECTRUM SWP Wound Polypropylene Filter Cartridge is your trusted solution for consistent, effective filtration. Engineered with precision and crafted using FDA-compliant polypropylene materials, this filter cartridge sets the standard for quality, versatility, and durability. Whether you're tackling sand, silt, or rust, the SWP delivers reliable performance across various industries.
Key Features
Advanced Filtration DesignExact computer-controlled winding ensures reliable particulate removal throughout the media.
Wide Range of Micron SizesAvailable in options from 0.5 µm to 150 µm, suited for diverse filtration needs.
Versatile SizingComes in standard diameters with lengths ranging from 10” to 40”. Large diameter 10” and 20” cartridges are also available to reduce changeout frequency.
Premium Material ConstructionMade with polypropylene media and core, ensuring broad chemical compatibility and high-temperature resistance.
Graded Density for LongevityConstructed with graded density to maximize dirt-holding capacity, making it ideal for varying particulate sizes.
Benefits at a Glance
Proven performance with over 50 years of efficiency.
Designed to meet FDA compliance for safety and quality.
Reduces maintenance efforts with high dirt-holding capacity.
Suitable for a wide variety of industries and applications.
Applications & Industries
The SPECTRUM SWP Filter Cartridge is highly adaptable, making it the ideal choice for:
Removing sand, silt, and rust in water systems.
Filtering chemicals during manufacturing processes.
Metal finishing and surface coating applications.
Protecting valves, pumps, and nozzles from particle damage.
TruDepth Standard spun cartridges from SPECTRUM are one of 4 cartridges available in the TruDepth range, alongside the Economic, Premier and High Efficiency cartridges. Each a different grade to match the wide variety of liquid applications where a broad range of particles are to be removed.Each grade is manufactured from only FDA compliant polypropylene with no binders, resins or glues ensuring no leeching into the liquid stream. All cartridges in the TruDepth range use melt-blown technology to form their 3D micropore matrices with different fine fibres used to create a strong structure with coarser filtration on the surface and finer filtration on the inner. This gradual reduction in size allows the cartridges to be used where a wide band of pollutant sizes exist. Contaminants such as particles, dirt, debris and rust are removed by the TruDepth range to provide efficient filtration and excellent service life.The variants in construction are reflected in each of the range’s performance. The finer fibres and deep grooves used in the Premier range for instance offer benefits in maximising the filtration surface area which increases the flow rate and lowers the pressure drop across the cartridge as well as maximising the dirt-holding capability and extending the service life. The Premier range also benefits from offering end-cap and seal options.Choosing the cartridge grade that is fit for the purpose is dependent upon the individual application requirements of temperature, pressure, band of particle size to be removed, requirements of housing to accept specific end-caps, approvals, sizes, lengths and micron ratings.Key Product Features
Unique mini-grooved construction for enhanced dirt holding
Strong self-supporting matrix
Best value, certified, general use cartridge option
Typically used for Pre-RO water treatment, food and beverage and Public water supply
Features & Information
Constructed from lot controlled, FDA approved materials
Superior manufacturing technology over wound cartridges results in an economic, reliable pre-filter
A true-graded density filter that incurs no surface blinding
Contains no solvents, binders or anti-static agents
Broad application compatibility
Available in large diameter 10" and 20" lengths for reduced cartridge changeout frequency
Applications & Industries
General incoming water filtration
Pre RO water treatment
Nozzle and pump protection
Food
Beverage
Chemical manufacture
Low levels of energy are required to flow liquids through these very efficient filters due to their exceptionally large surface area.The innovative fibrous polyester media used in the construction of these filters increases the dirt holding capability when compared to single sheet media due to the depth characteristics of the packed fibres. The use of resilient polyester media also means the filters can be used with microbiologically untreated liquids such as borehole and river water, as well as harsher chemicals, like those used in the plating industry for instance, making them the ideal choice for a variety of incoming liquid applications.WRAS approved, these cartridges are capable of removing dirt, sand, sediment and other particulate at a highly efficient rate of 90% at the stated micron level. Constructed using bonded vinyl plastisol end-caps ensures the integrity of the pleat pack which is then further enhanced by the use of a tough polypropylene core. The moulded end-caps means no lost end-caps during changeouts and their malleability ensures the optimum seal against the knife-edge of the housing during service.With almost 7 times the surface area of a cylindrical filter, the pleated construction maximises the amount of media used which then optimises service life and makes these cartridges very economical to use.Maximum temperature 38°CKey Product Features
90% efficiency
Very low pressure drop meaning low energy requirement
High surface area for high flow potential
Depth characteristics ensures high dirt holding capability
WRAS approved
Full range of sizes, lengths and micron ratings available
Applications and Industries
General particulate removal for incoming water filtration
Pre or final stage filtration
High flow applications
Aquafilter FCPP100 Cartridges
Introducing the Aquafilter FCPP100 100 micron polypropylene yarn cartridges, specifically designed for water filtration systems. These high-quality cartridges are crafted to efficiently remove sediments and impurities from your water supply, ensuring clean and safe drinking water for you and your family.
Water Filter Efficiency
The Aquafilter FCPP100 cartridges excel in sediment removal, trapping particles as small as 100 microns to provide you with crystal clear water. With a pack of 50 cartridges, you can enjoy consistent and reliable filtration over an extended period, giving you peace of mind knowing that your water is free from contaminants.
Quality Construction
Made from durable polypropylene yarn, these cartridges are built to last and withstand the rigors of water filtration. The 10-inch size ensures compatibility with a wide range of filter systems, making it easy to upgrade your current setup for improved water quality. Invest in the Aquafilter FCPP100 cartridges today for effective water purification at home or in commercial settings.
Efficient Sediment Removal
Keep your water clean and clear with the 25pk Aquafilter FCPP50 50 micron polypropylene yarn cartridges. Designed for use with Aquafilter water filters, these cartridges are specifically engineered to efficiently remove sediment, dirt, and other impurities from your water supply. With a 50 micron rating, these cartridges effectively capture even the smallest particles, ensuring your water is free from contaminants.
Premium Quality Filter
Made from high-quality polypropylene yarn, these cartridges are durable and long-lasting, providing you with clean and healthy water for an extended period of time. The Aquafilter FCPP50 cartridges are designed to fit 10" filter housings, making them compatible with a wide range of water filter systems. Easy to install and replace, these cartridges are a cost-effective solution for maintaining your water filtration system.
Convenient Pack
This pack includes 25 Aquafilter FCPP50 cartridges, ensuring you have an ample supply on hand for regular maintenance and replacement. Whether you're a homeowner looking to improve the quality of your drinking water or a business owner in need of reliable filtration solutions, these cartridges are a practical choice. Trust Aquafilter for all your water filtration needs and enjoy clean, sediment-free water every day.
Aquafilter FCCEL10
Ensure clean and pure water in your household with the 10pk Aquafilter FCCEL10 sediment cartridge. This high-quality water filter is designed by Aquafilter, a trusted brand in water filtration systems. The 10 micron multi-use polyester fabric pleated cartridge effectively removes sediments and particles from your water supply for improved taste and quality.
Durable Polyester Material
Made from durable polyester fabric, the Aquafilter FCCEL10 sediment cartridge is built to last. The pleated design provides a larger surface area for better filtration performance and longer lasting use. Say goodbye to frequent filter replacements and enjoy clean water without the hassle.
Multi-Use Cartridge
The Aquafilter FCCEL10 sediment cartridge is versatile and suitable for various water filtration applications. Whether you are looking to use it in your home, office, or recreational vehicle, this cartridge can meet your needs. Trust Aquafilter to deliver reliable and efficient water filtration solutions for your everyday use.
Affordable Replacement Cartridges
Keep your FP2 series and RO systems running smoothly with this set of 3 replaceable cartridges. These water filters are designed to effectively remove impurities and contaminants from your drinking water, ensuring clean and fresh water every time you turn on the tap. With regular replacement, you can enjoy peace of mind knowing that your water is safe for consumption.
Enhanced Filtration Performance
Each cartridge in this filter set is specially designed to target different types of impurities, including sediment, chlorine, and other harmful substances. The combination of these cartridges allows for thorough filtration, resulting in crisp and refreshing drinking water that is free from unpleasant tastes and odors. Upgrade your water filtration system with these high-quality cartridges for superior performance.
Easy to Install and Replace
Installing and replacing these cartridges is a breeze, thanks to their user-friendly design. Simply follow the included instructions to quickly and easily swap out old cartridges for new ones. With this convenient set of 3 replacements, you can ensure that your FP2 series or RO system continues to provide you with clean and great-tasting water for months to come.
Maintain your Aquafilter EXCITO-ST water filtration system with the Aquafilter EXCITO-HF-CRT 3-Piece Replacement Cartridge Set. Designed specifically for the EXCITO-ST system configured with the optional TLCHF-FP ultrafiltration membrane, this genuine Aquafilter cartridge set provides the pre-filtration, water conditioning and activated carbon treatment needed to support your drinking water filtration system.
The three inline cartridges work alongside the separate TLCHF-FP ultrafiltration membrane to help reduce sediment, chlorine, selected organic substances, iron and certain heavy metals. The combination of sediment filtration, ion-exchange media, activated carbon and KDF helps improve filtered water taste and odour while providing additional water treatment.
Designed for EXCITO-ST with an ultrafiltration membrane
The EXCITO-HF-CRT is the dedicated three-cartridge replacement set for the Aquafilter EXCITO-ST system when used with the TLCHF-FP capillary ultrafiltration membrane.
Unlike the standard four-cartridge EXCITO-ST-CRT set, this configuration uses a different second-stage cartridge and replaces the usual final sediment cartridge position with the separate ultrafiltration membrane.
The three replacement cartridges are:
1 × AIPRO-20M-AQ sediment cartridge
1 × AIPRO-3-L-AQ multi-function conditioning cartridge
1 × AICRO-L4-AQ activated carbon and KDF cartridge
Please note: The TLCHF-FP ultrafiltration membrane is not included in this three-piece cartridge set. It must be purchased separately.
Three-stage replacement cartridge set
Stage 1 – AIPRO-20M-AQ sediment cartridge
The first cartridge uses polypropylene filtration media with a nominal 20-micron rating.
It provides initial mechanical filtration, helping to reduce suspended particles before water passes through the subsequent treatment stages.
It helps capture:
Sand
Silt
Rust particles
Sediment
Other suspended solids
This pre-filtration stage helps protect the downstream cartridges and ultrafiltration membrane from larger particles.
Stage 2 – AIPRO-3-L-AQ multi-function conditioning cartridge
The second cartridge combines several filtration media to provide additional water conditioning.
Its layered construction incorporates polypropylene foam, conditioning media and ion-exchange media. It is designed to help reduce suspended particles, iron and iron derivatives, while also reducing water hardness.
Benefits include:
Additional sediment filtration
Reduction of iron and selected iron compounds
Ion-exchange treatment to reduce water hardness
Improved water conditioning before the final treatment stage
Actual performance depends on incoming water quality, contaminant levels and cartridge condition.
Stage 3 – AICRO-L4-AQ activated carbon and KDF cartridge
The final cartridge combines granular activated carbon with KDF media.
Activated carbon helps reduce free chlorine and selected organic compounds, improving the taste and smell of filtered water. KDF media provides additional treatment of certain dissolved metals and has bacteriostatic properties that help inhibit bacterial growth within the cartridge.
Benefits include:
Reduction of free chlorine
Improved taste and odour
Reduction of selected organic substances
Treatment of certain metals, including iron and heavy metals
Bacteriostatic properties from KDF media
Compatible with the TLCHF-FP ultrafiltration membrane
This three-cartridge set is designed to operate alongside the Aquafilter TLCHF-FP capillary ultrafiltration membrane.
The optional membrane provides an additional filtration barrier using hollow-fibre technology. It is designed to retain fine suspended particles and certain microorganisms.
When used together, the three cartridges and UF membrane provide a four-stage filtration arrangement for the EXCITO-ST system.
Important: The TLCHF-FP membrane is sold separately and is not included in this product. This listing is for the three replacement cartridges only.
Genuine Aquafilter replacement cartridges
Using the correct replacement cartridges helps maintain the intended filtration configuration of your EXCITO-ST system.
The EXCITO-HF-CRT set is designed for the EXCITO-ST configuration with the TLCHF-FP membrane. It should not be confused with the standard EXCITO-ST-CRT four-cartridge replacement set.
Check your existing system configuration before ordering to ensure you select the correct replacement set.
Product benefits
Genuine Aquafilter replacement cartridge set
Three inline cartridges for the EXCITO-ST system
Designed for use with the optional TLCHF-FP ultrafiltration membrane
Helps reduce sediment, sand, silt and rust
Helps reduce iron and selected iron compounds
Ion-exchange media helps reduce water hardness
Activated carbon helps reduce chlorine and improve taste and odour
KDF media provides additional treatment of certain metals
1/4-inch NPT connections
Compact 2.5 × 12-inch cartridge format
Technical specifications
Specification
Details
Brand
Aquafilter
Cartridge set model
EXCITO-HF-CRT
Compatible system
Aquafilter EXCITO-ST
Set contents
3 inline filter cartridges
Cartridge 1
AIPRO-20M-AQ
Cartridge 2
AIPRO-3-L-AQ
Cartridge 3
AICRO-L4-AQ
Filtration media
Polypropylene, conditioning media, ion exchange, activated carbon and KDF
Nominal micron rating
20 microns
Cartridge size
2.5 × 12 inches
Connection type
1/4-inch NPT
UF membrane compatibility
TLCHF-FP
UF membrane included
No
Application
Replacement cartridges for EXCITO-ST under-sink filtration system
Installation and maintenance
Before replacing the cartridges, shut off the water supply and follow the Aquafilter installation instructions for your EXCITO-ST system.
When fitting the new cartridges:
Check the model and connection compatibility before installation.
Observe the direction-of-flow arrow marked on each cartridge.
Ensure all threaded connections are properly sealed.
Check all connections for leaks after restoring the water supply.
Flush the system after cartridge replacement before using the filtered water.
Aquafilter also specifies that the EXCITO-ST system must be protected against pressure surges using the appropriate pressure regulator.
For an EXCITO-ST system fitted with the TLCHF-FP ultrafiltration membrane, Aquafilter specifies the PLV-0104-50 regulator (50 psi / approximately 3.3 bar). The regulator is not included with the system.
Always follow the manufacturer's installation and maintenance instructions.
Package contents
1 × AIPRO-20M-AQ sediment cartridge
1 × AIPRO-3-L-AQ multi-function conditioning cartridge
1 × AICRO-L4-AQ activated carbon and KDF cartridge
Not included: Aquafilter TLCHF-FP ultrafiltration membrane, EXCITO-ST filtration unit, pressure regulator or additional installation accessories.
Hand-held oxygen and temperature meter with NFC and Bluetooth technology
The Polaris C LDO Optical meter is an almost maintenance free meter for measuring dissolved oxygen and temperature. The meter is sturdy, easy to use and has an extensive longevity making it ideal for harsh conditions.Polaris C LDO can store up to 2500 complete set of data, including time and date stamps. The logged data can be stored either manually or automatically with the possibility to group the data into categories.
The stored data can be uploaded directly to Cobália using Bluetooth technology. Scan the Cobália NFC tag on the tank and all data will be uploaded to your “digital farm”. Tank specific data assigned to the tags will be stored in Cobália for analysis on temporal variation, generation of graphs and for multivariable analysis on performance.
The meter has a built-in self-check of all hardware, it compensates automatically for barometric pressure and it has a notably short response time. With this meter, you get the high-quality associated with OxyGuard technology and a product that will serve you well for many years.
Improve your property's incoming water supply with the Aquafilter 20" Big Blue 3-Stage Whole House Water Filter and Softener Kit.
Designed for whole-house water treatment, this system combines three stages of filtration to help reduce suspended particles, improve chlorine-related taste and odour, and address water hardness.
Using three large-format 20" x 4.5" Big Blue cartridges, the system provides a practical solution for domestic properties and suitable light-commercial installations where sediment filtration, carbon treatment and hardness reduction are required.
The three-stage configuration is designed to treat incoming water before it is distributed throughout your property, helping protect plumbing and water-using appliances while improving general water quality.
With 1" plumbing connections and a robust triple-housing arrangement, this system is suitable for compatible whole-house filtration installations.
Key Features
Three-stage filtration: Combines sediment, carbon and water-softening cartridges.
Sediment reduction: Helps capture suspended particles such as sand, rust, silt and dirt.
Chlorine taste and odour reduction: Carbon filtration helps improve water affected by chlorine-related tastes and smells.
Water hardness reduction: A specialist ion-exchange cartridge helps reduce calcium and magnesium under suitable operating conditions.
Limescale management: Reducing hardness minerals can help limit scale formation in plumbing and appliances.
Large-format cartridges: Uses three 20" x 4.5" Big Blue cartridges.
Whole-house application: Designed for installation on a compatible incoming water supply.
1" connections: Suitable for compatible plumbing systems.
Replaceable cartridges: Individual filter cartridges can be replaced during routine maintenance.
How the Three Filtration Stages Work
The system combines three different filtration functions to address common water-quality concerns.
Stage 1 – Sediment Filtration
The first stage uses a suitable 20-inch sediment cartridge to help capture suspended particles such as:
Sand
Rust
Silt
Dirt
Other suspended sediments
This initial filtration stage helps protect the downstream carbon and softening cartridges from excessive particulate loading.
Stage 2 – Activated Carbon Filtration
The second stage uses activated carbon filtration media to help reduce chlorine and improve water taste and odour.
Carbon filtration can be particularly useful where chlorine affects the smell or taste of the incoming water supply.
Stage 3 – Water Softening
The third stage uses a specialist ion-exchange-based softening cartridge to help reduce calcium and magnesium, the minerals primarily responsible for water hardness.
Reducing these minerals can help limit limescale formation in pipes, taps, showers and water-using appliances.
This cartridge-based treatment has a finite capacity and is not equivalent to a conventional automatically regenerating water softener.
What's Included in the Kit?
The kit is designed around three 20" x 4.5" Big Blue cartridges.
The matching replacement cartridge configuration listed by GroAqua identifies:
1 x FCPS5M20B sediment cartridge.
1 x PRISM Plus carbon block cartridge.
1 x FCCST20BB water-softening cartridge.
Please confirm these exact cartridge codes against the physical kit before publishing them as included components.
The complete housing assembly and accessories should also be listed here once confirmed, including the number of pressure gauges, mounting platform, housing wrench and any centering discs supplied.
Suitable Applications
This 20" Big Blue three-stage system may be suitable for:
Domestic whole-house water filtration.
Properties experiencing hardness-related limescale formation.
Incoming water supplies where chlorine taste and odour are a concern.
Properties requiring sediment and carbon filtration.
Suitable light-commercial water treatment installations.
For best results, test the incoming water before installation. Water hardness, chlorine concentration, pH, iron levels and general water chemistry can affect cartridge performance and service life.
Product Specifications
Brand: Aquafilter
System type: Three-stage Big Blue whole-house filtration and softening system
Housing size: 20" Big Blue
Cartridge configuration: 3 cartridges
Cartridge dimensions: 20" x 4.5"
Inlet/outlet connections: 1"
Operating pressure: Up to 6 bar
Listed maximum flow rate: 21 litres per minute
Published dimensions: 785 x 540 x 220 mm (H x W x L)
Additional technical specifications, including minimum and maximum water temperature, housing materials and included accessories, should be confirmed against the manufacturer's documentation.
The listed 21 lpm flow rate should be checked against the complete assembled system and the specific cartridges fitted.
Installation and Maintenance
Install the system on a suitable incoming water supply using compatible plumbing connections.
Allow sufficient clearance around the housings to remove cartridges during routine servicing.
Inspect the system regularly for leaks and monitor pressure changes where gauges are fitted. Replace cartridges according to their individual manufacturer recommendations and the condition of the incoming water.
The softening cartridge has a finite treatment capacity. Its replacement interval depends on incoming water hardness, water consumption and operating conditions.
For properties with particularly hard water or high water consumption, a conventional regenerating water softener may be a more suitable solution.
Important Water Treatment Information
This system combines sediment filtration, activated carbon treatment and cartridge-based hardness reduction.
Carbon filtration can help reduce chlorine and improve taste and odour. Sediment cartridges help capture suspended particles. The softening cartridge helps reduce calcium and magnesium.
The system should not be considered a universal water purifier or microbiological disinfection system. It should not be assumed to remove all dissolved contaminants, bacteria, viruses or other microorganisms.
If your water supply is untreated or microbiologically unsafe, appropriate testing and a suitably validated treatment system are required.
Improve your incoming water supply with the Aquafilter 20" Big Blue 3-Stage Whole House Water Filter and Iron Reduction Kit.
Designed for whole-house water treatment, this three-stage filtration system combines sediment filtration, activated carbon treatment and specialist iron-reduction media to help address common water-quality problems.
Iron in water can contribute to orange and brown staining on sinks, baths, toilets, laundry and plumbing fixtures. Depending on its concentration and form, it can also affect water colour, taste and appearance.
This Big Blue filtration system is designed to help reduce iron while providing additional sediment and carbon filtration. Its three large-format 20" x 4.5" cartridges offer a practical configuration for compatible domestic and light-commercial water-treatment installations.
Key Features
Three-stage filtration: Combines sediment, carbon and specialist iron-reduction treatment.
Iron reduction: Uses dedicated filter media to help reduce iron in suitable water supplies.
Sediment filtration: Helps capture suspended particles such as sand, rust, silt and dirt.
Carbon filtration: Helps improve water taste and odour and reduce chlorine, depending on cartridge performance and operating conditions.
pH adjustment: The specialist iron-reduction cartridge is also listed as a pH-adjusting cartridge.
Large-format cartridges: Uses three 20" x 4.5" Big Blue filter cartridges.
Whole-house installation: Designed to treat incoming water before distribution around a property.
1" plumbing connections: Suitable for compatible plumbing installations.
Replaceable cartridges: Individual filter cartridges can be replaced as part of routine maintenance.
How the Three Filtration Stages Work
Stage 1 – Sediment Filtration
The first stage uses a 5-micron sediment cartridge to help capture suspended particles from the incoming water supply.
It is designed to help reduce:
Sand
Rust particles
Silt
Dirt
Other suspended sediments
This initial filtration stage helps protect the downstream treatment cartridges from excessive particulate loading.
Stage 2 – Activated Carbon Filtration
The second stage uses an activated carbon cartridge to help improve water quality by reducing chlorine-related taste and odour.
Carbon filtration can be particularly useful where the incoming water supply has an unpleasant chlorine taste or smell.
Its performance depends on the cartridge specification, water chemistry, contact time and flow rate.
Stage 3 – Iron Reduction and pH Adjustment
The third stage uses a specialist iron-reduction cartridge.
The FCCFE20B cartridge is listed by GroAqua as an iron-reducing and pH-adjusting cartridge. It is intended to help address iron-related water-quality issues and may be useful where iron contributes to discolouration and staining.
Iron-treatment performance depends on the concentration and form of iron in the incoming water, as well as pH and other water-quality conditions.
Water testing is recommended before selecting an iron-reduction system.
What's Included in the Kit?
The matching three-cartridge replacement configuration identifies:
1 x FCPS5M20B 5-micron sediment cartridge.
1 x PRISM Plus activated carbon cartridge.
1 x FCCFE20B iron-reducing and pH-adjusting cartridge.
The complete filtration assembly is specified as a three-housing 20" Big Blue system.
Confirm the supplied housing assembly and accessories before listing them as included. These may include the mounting platform, pressure gauges, housing wrench and BACINIX bacteriostatic centering discs.
Suitable Applications
This system may be suitable for:
Domestic whole-house water filtration.
Water supplies affected by iron-related staining.
Properties experiencing orange or brown water discolouration.
Incoming water requiring sediment filtration and carbon treatment.
Suitable light-commercial water-treatment installations.
Properties where water testing identifies iron levels suitable for cartridge-based treatment.
For best results, test the incoming water before installation. Important parameters include:
Total iron concentration.
Ferrous and ferric iron content.
pH.
Manganese concentration.
Suspended solids.
Water flow and daily consumption.
The results will help determine whether this cartridge-based system is appropriate or whether a dedicated iron-removal treatment system is required.
Product Specifications
Brand: Aquafilter
System type: Three-stage Big Blue whole-house filtration and iron-reduction system
Housing size: 20" Big Blue
Cartridge configuration: 3 cartridges
Cartridge dimensions: 20" x 4.5"
Inlet/outlet connections: 1"
Maximum operating pressure: 6 bar
Listed maximum flow rate: 210 litres per minute
Published dimensions: 785 x 540 x 220 mm (H x W x L)
The listed maximum flow rate should be confirmed against the manufacturer's specification for the complete system with the supplied cartridges installed. Actual flow will depend on cartridge resistance, incoming pressure, water quality and plumbing conditions.
Installation and Maintenance
Install the filtration system on a suitable incoming water supply using compatible 1" plumbing connections.
Allow sufficient clearance around the housings to make cartridge replacement and servicing straightforward.
During operation:
Check the system regularly for leaks.
Monitor pressure gauges where fitted.
Inspect cartridges according to the manufacturer's maintenance guidance.
Replace cartridges when their recommended service life is reached or performance deteriorates.
Retest water quality where iron reduction is a primary treatment requirement.
Cartridge service life depends on incoming water quality, iron concentration, sediment loading, water consumption and operating conditions.
Important Water Treatment Information
This system combines sediment filtration, activated carbon treatment and specialist iron-reduction media.
Iron-reduction performance depends on the type and concentration of iron present in the water. Dissolved ferrous iron, oxidised ferric iron and particulate iron can behave differently during filtration.
The system should not be assumed to remove every form of iron or manganese under all conditions. Water analysis is recommended to confirm suitability.
This is a filtration system, not a universal water purifier or microbiological disinfection system. It should not be assumed to remove bacteria, viruses or all dissolved contaminants, or to make microbiologically unsafe water safe to drink.
Improve the taste and odour of your household water with the Aquafilter 20" Big Blue 3-Stage Whole House Water Filter and Dechlorinator Kit.
Designed for installation on a property's incoming water supply, this three-stage filtration system combines sediment filtration with carbon-based treatment to help reduce chlorine and improve the overall taste and smell of water throughout the home.
Chlorine is commonly used to disinfect public water supplies, but some households find its taste and smell unpleasant. Activated carbon filtration can help reduce free chlorine, making it a useful option for people looking to improve the sensory quality of their water.
With three large-format 20" x 4.5" cartridges and 1" plumbing connections, this Big Blue system is designed for compatible whole-house domestic water installations.
Key Features
Three-stage filtration: Combines sediment and carbon-based filtration.
Chlorine reduction: Activated carbon media can help reduce free chlorine.
Improved taste and odour: Helps address chlorine-related tastes and smells.
Sediment filtration: Helps capture suspended particles such as sand, rust and silt.
Whole-house installation: Designed to filter incoming water before it reaches household outlets.
Large-format cartridges: Uses three 20" x 4.5" Big Blue cartridges.
1" connections: Suitable for compatible domestic plumbing systems.
Replaceable cartridges: Allows routine maintenance using compatible replacement filters.
How the Three Filtration Stages Work
Stage 1 – Sediment Filtration
The first stage helps capture suspended particles from the incoming water supply.
Depending on the cartridge fitted, this stage can help reduce:
Sand
Rust particles
Silt
Dirt
Other suspended sediments
Sediment filtration also helps protect the downstream carbon cartridges from excessive particulate loading.
Stage 2 – Carbon Block Filtration
The second stage uses activated carbon block filtration to help reduce chlorine and improve water taste and odour.
Carbon block cartridges provide a filtration medium designed to bring water into contact with activated carbon. Performance depends on the cartridge specification, water quality, contact time and operating flow rate.
Stage 3 – Additional Carbon Treatment
The third stage provides additional carbon-based treatment, depending on the supplied cartridge configuration.
Where a granular activated carbon cartridge is fitted, it provides another carbon filtration stage to help reduce chlorine-related taste and odour and address certain other substances that activated carbon is designed to adsorb.
The performance of this stage depends on the specific carbon media and the water being treated.
What's Included?
The system is specified as a three-cartridge 20" Big Blue filtration configuration.
The matching GroAqua three-cartridge replacement set identifies the following possible cartridge combination:
1 x FCPS5M20B – 5-micron melt-blown sediment cartridge.
1 x PRISM Plus – activated carbon block cartridge.
1 x FCCA20B – granular activated carbon cartridge.
Please confirm the supplied cartridge models against the actual kit before ordering. Cartridge configurations can vary, and the exact replacement set should match the filters originally supplied.
Suitable Applications
This system may be suitable for:
Domestic whole-house water filtration.
Properties supplied with chlorinated mains water.
Reducing chlorine-related taste and odour.
Improving the sensory quality of water used for drinking and cooking.
General sediment filtration.
Compatible light-commercial water-treatment installations.
It is particularly relevant to households that want to treat incoming water before it is distributed to kitchen taps, bathrooms, showers and other outlets.
Product Specifications
Brand: GroAqua / Aquafilter
System type: Three-stage whole-house water filter and dechlorinator
Housing size: 20" Big Blue
Cartridge configuration: 3 cartridges
Cartridge dimensions: 20" x 4.5"
Inlet/outlet connections: 1"
Maximum operating pressure: 6 bar
Listed maximum flow rate: 210 litres per minute
Published dimensions: 785 x 540 x 220 mm (H x W x L)
The listed maximum flow rate should be verified against the manufacturer's documentation for the complete assembled system. Actual operating flow will depend on the cartridges installed, incoming pressure, water quality and plumbing conditions.
Installation and Maintenance
Install the system on a suitable incoming water supply using compatible 1" plumbing connections.
Allow enough space around the housings for servicing and cartridge replacement.
For effective ongoing operation:
Check connections and housings regularly for leaks.
Monitor pressure where gauges are fitted.
Replace cartridges in accordance with manufacturer recommendations.
Consider incoming water quality and household consumption when planning maintenance.
Check chlorine reduction performance if maintaining a particular treatment level is important.
Cartridge lifespan depends on water quality, chlorine concentration, sediment loading, consumption and operating conditions.
Important Filtration Information
This system uses sediment and carbon-based filtration to help improve water taste and odour and reduce chlorine.
Carbon filtration performance depends on the type of carbon cartridge, water chemistry, flow rate and contact time.
This system should not be regarded as a universal water purifier or disinfection system. It should not be assumed to remove bacteria, viruses or every dissolved contaminant, or to make microbiologically unsafe water safe to drink.
For applications requiring specific contaminant reduction, select cartridges with appropriate independently verified performance data.
Choose the Right Big Blue System
If your main concern is chlorine taste and odour, this three-stage dechlorinator kit is designed for that purpose.
If your water has iron-related staining, consider a dedicated iron-reduction system. If hardness and limescale are your main concerns, consider a cartridge-based softening system instead.
Choosing treatment according to your incoming water quality helps ensure that you select the right filtration configuration for your property.
Improve the taste and odour of your household water with the Aquafilter 20" Big Blue 3-Stage Whole House Water Filter and Dechlorinator Kit.
Designed for installation on a property's incoming water supply, this three-stage filtration system combines sediment filtration with carbon-based treatment to help reduce chlorine and improve the sensory quality of water throughout your home.
Chlorine is commonly used to disinfect public water supplies, but its taste and smell can be noticeable at household taps. Activated carbon filtration can help reduce free chlorine, making this system a practical option for households looking to improve the taste and odour of their water.
Featuring three large-format 20" x 4.5" cartridges and 1" plumbing connections, this Big Blue system is designed for compatible whole-house domestic water installations.
Key Features
Three-stage filtration: Combines sediment and carbon-based filtration.
Chlorine reduction: Activated carbon media helps reduce free chlorine.
Improved taste and odour: Helps address unpleasant chlorine-related tastes and smells.
Sediment filtration: Helps capture suspended particles such as sand, rust and silt.
Whole-house application: Designed to treat incoming water before it reaches household outlets.
Large-format cartridges: Uses three 20" x 4.5" Big Blue filter cartridges.
1" plumbing connections: Suitable for compatible plumbing installations.
Replaceable cartridges: Individual filters can be replaced as part of routine maintenance.
How the Three Filtration Stages Work
Stage 1 – Sediment Filtration
The first stage helps capture suspended particles from the incoming water supply.
A suitable sediment cartridge can help reduce:
Sand
Rust particles
Silt
Dirt
Other suspended sediments
This initial stage also helps protect the downstream carbon cartridges from excessive particulate loading.
Stage 2 – Activated Carbon Block Filtration
The second stage uses activated carbon block media to help reduce free chlorine and improve water taste and odour.
Carbon block filtration provides a treatment medium that brings water into contact with activated carbon. Its effectiveness depends on the cartridge specification, incoming water quality, contact time and operating flow rate.
Stage 3 – Granular Activated Carbon Filtration
The third stage can provide additional carbon-based treatment using granular activated carbon (GAC), where this cartridge is included in the supplied configuration.
GAC is commonly used to adsorb free chlorine and certain substances that can affect water taste and odour.
The combination of carbon block and granular activated carbon provides two different carbon filtration formats within the system.
Actual treatment performance depends on the specific cartridges installed and the operating conditions.
What's Included?
The matching GroAqua 20" replacement cartridge configuration identifies:
1 x FCPS5M20B – 5-micron melt-blown sediment cartridge.
1 x PRISM Plus – activated carbon block cartridge.
1 x FCCA20B – granular activated carbon cartridge.
Please confirm these exact cartridge models against the complete kit before publishing them as included components.
The system itself is specified as a three-housing 20" Big Blue filtration assembly. Confirm the supplied installation accessories and fittings against the manufacturer's kit contents.
Suitable Applications
This three-stage dechlorinator system may be suitable for:
Domestic whole-house water filtration.
Properties supplied with chlorinated mains water.
Reducing chlorine-related taste and odour.
Improving the sensory quality of water used for drinking and cooking.
General sediment filtration.
Compatible light-commercial water-treatment installations.
Installing the system on a suitable incoming water supply allows treatment before water is distributed to kitchen taps, bathrooms, showers and other outlets.
Product Specifications
Brand: Aquafilter / GroAqua
System type: Three-stage whole-house water filter and dechlorinator
Housing size: 20" Big Blue
Cartridge configuration: 3 cartridges
Cartridge dimensions: 20" x 4.5"
Inlet/outlet connections: 1"
Maximum operating pressure: 6 bar
Listed maximum flow rate: 210 litres per minute
Published dimensions: 785 x 540 x 220 mm (H x W x L)
The listed maximum flow rate should be verified against the manufacturer's documentation for the complete assembled system. Actual flow depends on cartridge resistance, incoming pressure, water quality and plumbing conditions.
Installation and Maintenance
Install the filtration assembly on a suitable incoming water supply using compatible 1" plumbing connections.
Allow sufficient clearance around the housings for maintenance and cartridge replacement.
For reliable ongoing operation:
Check connections and housings regularly for leaks.
Monitor pressure where gauges are fitted.
Replace cartridges in accordance with manufacturer recommendations.
Consider incoming water quality and household consumption when planning maintenance.
Check chlorine reduction performance if a particular treatment level is required.
Cartridge lifespan depends on chlorine concentration, sediment loading, water consumption and operating conditions.
Important Filtration Information
This system combines sediment filtration and carbon-based treatment to help improve water taste and odour and reduce free chlorine.
Carbon filtration performance depends on the type of cartridge, water chemistry, contact time and flow rate.
This is not a universal water purification or disinfection system. It should not be assumed to remove bacteria, viruses or every dissolved contaminant, or to make microbiologically unsafe water safe to drink.
For applications requiring specific contaminant reduction, choose cartridges with appropriate independently verified performance data.
Explore Other Big Blue Water Treatment Systems
If chlorine taste and odour are your main concerns, this three-stage dechlorinator kit is designed for that application.
If your water has iron-related staining, consider a dedicated iron-reduction system. If hardness and limescale are the main problems, explore a suitable cartridge-based softening system.
Selecting the correct treatment according to your incoming water quality helps ensure that your filtration system is appropriate for your property.
Improved Water Filtration
The Aquafilter FCPS5M20B 2x FCCFE20B Big Blue 20 replacement cartridges set is designed to enhance the quality of your water by effectively filtering out impurities and contaminants. These cartridges are compatible with Big Blue 20 inch filter housings, providing a convenient and reliable solution for maintaining clean and healthy water in your home or business.
Effortless Installation
Replacing your old filter cartridges with the Aquafilter FCPS5M20B 2x FCCFE20B set is a quick and simple process that requires no special tools or expertise. Each cartridge is designed to fit securely in your filter housing, ensuring a tight seal and maximum filtration efficiency. With this set, you can enjoy clean and great-tasting water with ease.
Long-Lasting Performance
Constructed from high-quality materials, the Aquafilter FCPS5M20B 2x FCCFE20B cartridges are built to last, providing consistent filtration performance over an extended period. With regular maintenance and replacement, these cartridges will help prolong the life of your filtration system and ensure that your water remains pure and safe for consumption.
Aquafilter set of 3 Big Blue 20" replacement cartridges set:
1 x FCPS5M20B- melt-blown 5 micron sediment filter cartridge
2 x PRISM Plus carbon block
Filter Life: 6-12 months or 257000 litres
Aquafilter set of 3 Big Blue 10" replacement cartridges set:
FCPP5M10B- sediment 5 micron polypropylene yarn cartridges
Ecosoft Carbon cartridge
FCCBKDF210BB- coconut shell GAC carbon cartridge with KDF and softening media
Filter Life: 6-12 months or 53000 litres
Aquafilter set of 3 Big Blue 10" replacement cartridges set:
1x FCPS5M10B- melt-blown 5 micron sediment filter cartridge
2x PRISM Plus Carbon Cartridge
Filter Life: 6-12 months or 123000 litres
