A robust and intuitive range of portable meters, instilling confidence in reporting and managing your results.
The HQ Series is for water quality professionals who want to perform electrochemical analysis for field and lab environments. Our new portable platform will allow you to collect intuitive, accurate measurements, manage data, and easily review results, while supplying an IP67 robustness rating.They provide a true rugged, field-ready solution with on-screen, visual step-by-step operating guidance that provides users with confidence in reporting and managing their results. Unlike other field meters with basic user interfaces and without easily accessible data, the HQ Series secures, simplifies, and accelerates the complete measurement process for field users.Choose from 4 models, including the three-input HQ4000 series, dual-input HQ2000 series, and single-input HQ1000 series. These meters offer a range in measurement versatility - eliminating the need for multiple pieces of equipment.
Performing a successful calibration has never been so simple
Deliver your daily activity in just a few clicks
Sensors designed for every application
Peace of mind: Hach service and support will be there for you
Luminescence-based LDO technology - no replacement of electrolyte, no interference by deposits or H2S
Intellical LDO101 is a digital, luminescent/optical dissolved oxygen (LDO) probe. This Rugged DO sensor version is built with a stainless steel body ensuring sufficient weight to the probe for an easy outside handling, the sensing part is protected by a shroud, and the connection is ensured by strong and visible yellow coloured cable onto which you can clip depth markers (optional accessories), making the LDO101 rugged models specially designed for field use. LDO101 Rugged is available with a 5, 10, 15, or 30 meters cable. The LDO101 is fitted with an automatic pressure sensor module and a temperature sensor. LDO101 probes are fully calibrated at the factory. New LDO101 probes no longer require iButtons. The days in use tracking feature and the remaining sensor cap life reminder are initialized on the day of first use. The LDO101 Rugged is ideal for measuring dissolved oxygen in all type of external environment such as river, surface and ground waters, ponds, lakes, sea, wastewater plant, source water, drinking water reservoir for water quality, environmental and treatment process purposes.
Hach Intellical LDO is a revolutionary breakthrough in the measurement of dissolved oxygen, eliminating the numerous reliability and maintenance concerns inherent of older DO measurement technologies.
Intellical Rugged digital probes can reliably test in the harshest environmental conditions
Intellical digital probes provide ultimate traceability in measurement history
Intellical digital probes alert the user when re-calibration is needed
Intellical digital probes can be moved between meters without the need to re-calibrate or re-enter measurement settings
Intellical CDC401 is a digital, graphite, 4-pole conductivity cell with a temperature sensor. This Rugged CDC401 version is built with a stainless steel body ensuring sufficient weight to the probe for an easy outside handling, the sensing part is protected by a shroud, and the connection is ensured by strong and visible yellow coloured cable onto which you can clip depth markers (optional accessories), making the CDC401 rugged models specially designed for field use. CDC401 Rugged is available with a 5, 10, 15, or 30 meters cable. The CDC401 Rugged is ideal for measuring electrical conductivity, salinity, resistivity, or total dissolved solids (TDS) in all types of external environment such as river, surface and ground waters, ponds, lakes, sea, wastewater plant, source water, drinking water reservoir for water quality, environmental and treatment process purposes.
Intellical Rugged digital probes can reliably measure conductivity in the harshest environmental conditions
Intellical digital probes provide ultimate traceability in measurement history
Intellical CDC401 digital conductivity probes alert the user when re-calibration is needed
Intellical CDC401 digital conductivity probes can be moved between meters without the need to re-calibrate or re-enter measurement settings
Intellical CDC401 rugged digital conductivity probes are waterproof up to 30 meters for 24 hours (IP67 rating)
A robust and intuitive range of portable meters, instilling confidence in reporting and managing your results.
The HQ Series is for water quality professionals who want to perform electrochemical analysis for field and lab environments. Our new portable platform will allow you to collect intuitive, accurate measurements, manage data, and easily review results, while supplying an IP67 robustness rating.They provide a true rugged, field-ready solution with on-screen, visual step-by-step operating guidance that provides users with confidence in reporting and managing their results. Unlike other field meters with basic user interfaces and without easily accessible data, the HQ Series secures, simplifies, and accelerates the complete measurement process for field users.Choose from 4 models, including the three-input HQ4000 series, dual-input HQ2000 series, and single-input HQ1000 series. These meters offer a range in measurement versatility - eliminating the need for multiple pieces of equipment.
Performing a successful calibration has never been so simple
Deliver your daily activity in just a few clicks
Sensors designed for every application
Peace of mind: Hach service and support will be there for you
The Milwaukee MW803 MAX Waterproof Low Range 4-in-1 pH/EC/TDS/Temp Tester is designed as an all-in-one solution for growers.
The Milwaukee MW803 MAX Waterproof 4-in-1 Tester offers:
ACCURACY
The MW803 MAX 4-in-1 tester is accurate to ±0.05 pH, EC/TDS to 2% Full Scale and ±0.5°C / ±1°F for temperature.
With automatic calibration and 5 memorized calibration points, the tester can be quickly and easily be calibrated to a higher accuracy compared with manual calibration.
LONG LIFE
The tester comes with a replaceable pH probe with a double junction probe design for longer life.
FAST RESPONSE
An exposed temperature probe is located close to the pH probe for fast temperature compensation.
WATERPROOF CONSTRUCTION
No more worries about dropping your tester while measuring. The MW803 is fully waterproof to IP65.
LIGHT WEIGHT
At just 3.5 ounces, the MW803 MAX is easy to handle at up to half the weight of other testers.
EASE-OF-USE
A large dual level LCD screen makes reading results easy while a stability indicator and hold function that freezes the display takes the guess work out.
DESIGN FEATURES
Fast easy to read results with large digital dual LCD readout.
Extreme accuracy to ±0.05 pH, EC / TDS 2% Full Scale and Temperature ±0.5 C / ±1 F.
Range 0.00 – 14.00 pH | EC 0 to 3999 uS/cm | TDS 0 - 2000 ppm | Temperature: 0.0 to 50.0 C / 32.0 to 122.0 F.
Lightweight and portable at just 3.5 ounces.
Easy measurement: just place the probe in the sample, gently stir, wait for the stability indication to show a stable reading and then freeze the reading.
Simple push button, automatic 1 or 2 point pH calibration with 5 saved calibration points and simple 1 point EC calibration.
Gel-filled, double junction pH electrode for low maintenance and high performance with exposed temp. sensor for fast readings.
Auto shut off after 8 minutes of non-use.
Fully waterproof to IP65.
Battery life approx. 100 hour of continuous use (batteries included).
CARE AND USE
The MW803 PRO Tester includes both a pH and EC electrode. Both need maintenance.
All pH sensors have a limited life and response time gets longer with age. Properly maintaining your pH pen tester will give you fast, accurate results for longer. So, be sure to order the Milwaukee pH Maintenance Kit code PH-Main at checkout time! This will be needed to help clean and condition the pH electrode before use!
EC sensors are more robust but can still be affected by residue build up.
Here are our top four tips.
1. Always store with the cap full of buffer or storage solution MA9015 not water.
2. Clean your Tester regularly by soaking in cleaning solution MA9016.
3. Calibrate after cleaning and/or storage before testing to adjust for changes in the pH and EC sensor.
4. Gently stir the PRO Tester in the sample for a faster result.
5. Rinse in water after every test.
Thank you for considering Milwaukee to help you take your results to the next level.
MW401 is a Portable Low Range Total Dissolved Solids (TDS) Meter with Automatic Temperature Compensation. This instrument has been designed for aquariums, aquaculture, labs, and water conditioning applications to meet the needs for equipment suited from hobbist to professional. It is also a great meter for food labs, and water treatment applications.
TDS testing provides a method to optimize chemical applications and minimize operational cost. In aquarium and aquaculture applications, high concentrations of solids (TDS) can reduce clarity in water can decrease photosynthesis in aquatic plants. In water conditioning, a high (TDS) level can affect the clarity and taste of potable drinking water.
The MW401 has a range of 0 to 1990 mg/L (ppm) with a 10 mg/L (ppm) resolution. This (TDS) meter is supplied complete with conductivity probe with 1 m (3.3') cable and calibration solution.
DESIGN FEATURES
0 to 1999 mg/l (ppm) range.
Fast, easy-to-read results with large digital LCD readout.
Supplied with conductivity probe attached to a 3 foot cable.
Accuracy to ±2% FS @ 25°C.
Lightweight and portable.
300 hours of battery life with continuous use (battery included).
SE510 Conductivity probe included.
Starter Calibration Solution MI0032B, 1382 ppm (included).
This Milwaukee 3-in-1 Low Range combo meter allows you to measure pH, EC (conductivity) and TDS with a single meter and one single probe.
WHAT PEOPLE ARE SAYING
"Superb meter, easy to use, great customer service."
"Best meter I have ever owned."
"The best meter on the market and Milwaukee customer service is the best."
"I have owned this meter for almost 8 years and only replaced the probe once. The calibration nobs are easy to use, and even when I am less then gentle with the thing it keeps on going. I wouldn't consider any other meter."
"Easy calibration features."
"Light weight and ergonomic."
SUMMARY
pH and TDS are critical for water conditioning and aquariums. Total Dissolved Solids in drinking water can effect clarity and taste of water. In addition, high TDS levels can effect the health of a fish in an aquarium. High concentrations of TDS can decrease clarity of water in aquariums and decrease photosynthesis in aquatic plants.
The Milwaukee MW801 PRO Low Range Combo Meter lets you easily and accurately test pH, conductivity and total dissolved solids (TDS) using a single meter and integrated probe.
Simple, portable and rugged. No more juggling multiple electrodes and wires. Automatic temperature compensaton included.
The MW801 is the ultimate solution for pH and nutrient management.
DESIGN FEATURES
The design of the MW801 is focused on simple operation and ruggedness. With a single probe, big screen, easy calibration, the MW801 is exceptionally simple to operate.
A tough meter build and a rugged but replaceable probe means that you can expect years of use.
The Milwaukee PRO Combo meter offers:
pH, conductivity / nutrient EC, TDS (ppm) with automatic temperature compensation.
A replaceable, integrated pH, EC, and TDS (ppm) probe with a single 3 foot cable for easy use (SE600 probe included).
A fiber junction on the pH sensor to reduce contamination when measuring fertilizer solutions.
A light weight and portable form factor at just 5.8 ounces with battery and just over 3 inches wide.
A large easy to read display.
Factory calibration with a simple, single point manual calibration for both pH and EC.
A reputation for a rugged build and long life
Specialized design for drinking water, aquaponic, and aquariums.
CARE AND USE
The MW801 PRO Combo Meter includes both a pH and EC sensor in the SE600 integrated probe. All pH sensors have a limited life and response time gets longer with age. EC sensors are more robust but can still be affected by residue build up. Both need maintenance. Properly maintaining your probe will give you fast, accurate results for longer. So, be sure to order the Milwaukee pH Maitenance Kit code PH-Main at checkout time! This will be needed to help clean and condition the pH/EC electrode before use!
Here are our top four tips.
1. Always store with the cap full of buffer or storage solution not water.
2. Clean your probe regularly by soaking in cleaning solution.
3. Calibrate after cleaning and/or storage before testing to adjust for changes in the pH and EC sensor.
4. Gently stir the probe in the sample for a faster result.
Thank you for considering Milwaukee to help you take your results to the next level.
The Handy Atmosphere is a hand-held meter designed to measure oxygen in gas. It can be used to measure the low oxygen content of packaging gas, the oxygen content of the air and the purity of oxygen gas from oxygen generators and the like.
DescriptionThe OxyGuard Handy Atmosphere is a hand-held meter designed to measure oxygen in gas. It can be used to measure the low oxygen content of packaging gas, the oxygen content of the air and the purity of oxygen gas from oxygen generators and the like. A separate brochure is found for a version designed to measure the oxygen content of the modified atmosphere inside food packages. Signal processing is performed using a microprocessor, which gives a number of advantages. Just as with other Handy instruments you can simply switch on and measure, but the use of microprocessor technology enables measurements to be supported by a range of advanced functions designed to make things even easier for you:
Features
Automatic Calibration
Choice of Language
Oxygen, temperature, barometric pressure.
Automatic self-check
Automatic Probe Check
Barometric Pressure Compensation
Extremely long battery life
Technical Data Sheet
H02A OxyGuard Handy Atmosphere
The OxyGuard Handy pH is a hand-held, pocket size pH or Redox meter designed for use in demanding, wet environments. The meter itself and the electrode assembly are waterproof. This instrument does not suffer from the classical problems associated with pH meters – the Handy pH is sealed so that water cannot enter the top of the electrode or the electronics. You can drop it into the water without damaging it! In the Handy pH these advantages are combined with microprocessor technology to give an instrument that is exceptionally easy to use.
DescriptionHand-held pH meter for demanding, wet environments The OxyGuard Handy pH is a hand-held, pocket size pH/redox meter designed for use in demanding, wet environments. The meter itself and the electrode assembly are waterproof. This instrument does not suffer from the classical problems associated with pH meters - the Handy pH is sealed so that water cannot enter the top of the electrode or the electronics. You can drop it into the water without damaging it! Tried-and-tested construction uses standard buffer solutions available anywhere. Fixed cable with waterproof cable glands - no connector problems. Electrode assembly with hermetically sealed preamplifier eliminates electrical noise and moisture problems. The electrode can be exchanged in a few seconds. Large, stable display with "low batt" indicator. 500 hours continuous operation from a standard 9V battery. Easy temperature compensation - just set the dial! Comes complete with carrying pouch and 2 bottles of buffer solution. Also measures redox - just fit a redox electrode, switch to "Redox" and measure.
Specification
Measuring range, redox: 0-1999 mV, positive or negative
Temperature compensation range: 0 - 50°C
Cable length: 1.5 meters
Operating conditions: 0 - 50°C
The Handy Salinity is a hand-held instrument specially designed for aquaculture use. Factory calibration and automatic temperature compensation make it very easy to use. The display shows the salinity directly. Temperature is also measured and shown in the display.
The instrument incorporates automatic check functions to ensure reliability. The probe is designed to be as trouble-free as possible, with features specially suited for aquacultural use. Inductive technology is used so that you don’t have to worry about deposits on the surface of the probe – all you have to do is ensure that the hole in the probe is open and relatively clean.
The OxyGuard portable CO2 meter is a reliable and easy-to-use instrument that measures dissolved carbon dioxide in water.
The OxyGuard portable CO2 meter is a reliable and easy-to-use instrument that measures dissolved carbon dioxide in water. The meter consists of a probe and a battery-powered transmitter. The latter has a display showing the CO2 concentration and an analog signal as output. The transmitter has an on/off switch, "slope" and "zero" adjustments. Battery charger (230V), calibration accessories and 3-m cable are included. A version with built-in data logger is available.
Description
Measures the CO2 gas pressure directly and is not affected by carbonates or other dissolved substances. It is therefore possible to achieve simple, continuous direct measurements of carbon dioxide in water that affects fish.
Methods such as test kits, laboratory analysis and the detection of pH changes are subject to disturbance from the dissolved substances found in aquaculture water. The OxyGuard CO2 measures only the CO2 that affects the fish, which is the free dissolved CO2 gas. It is reliable and accurate. Calibration accessories pack includes beaker with stirrer and magnet; 75 g of pH conditioner with dosing spoon; 100 mL of calibration solution with dosing syringe; and adjustment screwdriver.
Technical Data
G03 OxyGuard Portable CO2 Analyzer
The ProSolo ODO/T kit includes the digital ProSolo handheld, an optical dissolved oxygen and temperature probe assembly (4 or 10 meter cable length), and a soft-sided carrying case.
OverviewThe ODO/T probe assembly pairs with the ProSolo Handheld to form a complete sampling system. Featuring integral, digital sensors, the ODO/T is plug-and-play which minimizes time spent on instrument setup. Pro DIGITAL technology allows the handheld to automatically recognize connected sensors, so there is no need to tell the instrument what is connected. Optical Dissolved Oxygen (ODO) technology is non-consumptive, meaning oxygen is not consumed during the measurement. Flow dependence is non-existent and no stirring is required, resulting in the most accurate DO measurements available from a probe. The ODO sensor is not susceptible to interferences from other gases, drifts less and holds calibration longer than membrane covered sensors. Maintenance is a breeze with a simple, threaded optical cap that is good for at least two years. The ProSolo Handheld features an easy-to-read color display, large capacity memory, intuitive interface, rechargeable battery, and powerful data management software (KorDSS) for powerful, yet convenient sampling experience. Great for surface water, groundwater, coastal/estuarine, aquaculture, and wastewater applications!
Calibration
400 detailed calibration records can be stored and are available to view, download, and print
Certifications
CEC, CE; RoHS; IP-67; WEEE; FCC; UN Part III, Section 38.3, Test methods for lithium-ion batteries (Class 9)
Data Management
100 user-defined sites and 100 user-defined data ID tags; site pictures can be sent to the handheld via KorDSS
Display
Color, LCD graphic display; 3.9 cm width x 6.5 cm height
Languages
English, Spanish, German, French, Italian, Norwegian, Portuguese, Japanese, Chinese (Simplified & Traditional), Korean, Thai
Logging Capabilities
Single point or continuous with autostable feature
Memory
> 100,000 data sets
Operating Temperature
0 to 50 °C (32 to 122 °F)
Power
Rechargeable lithium-ion battery pack provides ~48 hours with the handheld only; battery recharge time is ~9 hours with the AC power adapter; the instrument can also be powered via AC or external power pack through the USB port
Size
8.3 cm width x 21.6 cm length x 5.6 cm depth (3.27 in x 8.5 in x 2.21 in)
Storage Temperature
0 to 45 °C (32 to 113 °F) with battery installed; 0 to 60 °C (32 to 140 °F) without battery installed
USB
Built-in micro USB On-The-Go port for PC connection, recharging/powering the handheld and connecting directly to a USB stick
Warranty
3-year handheld warranty
Weight
567 grams (1.25 lbs) with battery
YSI ProSolo Quick Start Guide
Manuals
626973-01 | ProDIGITAL User Manual | English
626973-03 | Manuel d'utilisation ProDIGITAL | Français
626973-06 | ProDIGITAL Benutzerhandbuch | Deutsche
626973-04 | Manuale d’uso ProDIGITAL | Italiano
626973-07 | ProDIGITAL 取扱説明書 | 日本人
626973-05 | Manual do Utilizador ProDIGITAL | Português
626973-08 | ProDIGITAL 用户手册 | 中文 (Simplified)
626973-02 | Manual de usuario de ProDIGITAL | Español
626973-09 | ProDIGITAL 用戶手冊 | 中文 (Traditional)
