10” in-line set: filter housing, with pressure relief valve and transparent sump, mounting bracket with screws, wrench, cartridge, bacteriostatic filter centralizing ring, instruction, color box. Available with brass inserts: 1/2", 3/4" or 1" BSP. The design in combination with two O-rings (one inside filter head and second on the edge of filter sump), ensures maximum leak proof performance.FHPR12-B1-AQ - 1/2"FHPR34-B1-AQ - 3/4"FHPR1-B1-AQ - 1"
10” two stage system with two blue filter heads with BSP brass inserts, and two transparent filter housing sumps, wrench and color box.Set includes: FHPRCLx-B-TWIN system, wrench, 2 bacteriostatic centering rings, instruction and color box.System is available with several connection types:FHPRCL12-B-TWIN - 1/2" BSP,FHPRCL34-B-TWIN - 3/4" BSP.
10” in line filter housing with pressure relief valve and two o-rings, blue sump. Available with brass inserts: 1/2", 3/4" or 1" BSP. The design in combination with two O-rings (one inside filter head and second on the edge of filter sump), ensures maximum leak proof performance.FHPRN12 - 1/2"FHPRN34 - 3/4"FHPRN1 - 1"
This complete 7 stage reverse osmosis system is ready to install made by Aquafilter. Made of NSF and WRAS certified components. Due to the high membrane quality it is possible to purify up to 280 litres of water per day. Small micron rating 0,0001 µm, allows to remove most contaminants from water including bacteria and viruses. System is equipped with post filtration carbon cartridge (AICRO), which improves the taste and aroma of water and AIMRO mineralising cartridge, which enriches water with elements such as calcium and magnesium.Set includes: RX-RO6-NN system, FCCA, FCCBL, FCPS20 sediment filter,(one extra sediment filter 5 micron), AICRO, AIMRO cartridges and TFC-75F-AQM RO membrane, FXFCH5 faucet, feed water connector 1/2″, tubing, tank, instruction, and accessories.If your water pressure is less than 2.8bar, we recommend you choose the pumped system.
Please find a link to the Instructions here. A QR Code linking to instructions is included in the box.
We recommend using a plumber or other suitable tradesperson for the installation of these systems.
UsesDrinking water for home and office Aquarium waterwindow cleaning
What we offer7 stage complete Ro filter system 75 GPD.(Stage 1) 20 Micron Sediment Filter: FCPS20 or FCPS5(Stage 2) Activated Carbon Block Filter: FCCBL(Stage 3) Carbon Block Filter: FCCA(Stage 4) Reverse Osmosis Membrane 75 GPD per day: TFC-75F-AQM(Stage 5) Post Carbon filter: AICRO(Stage 6) Mineral cartridge: AIMRO(Stage 7) Ionizing Cartr0dge: AIFIR2000.
FeaturesConnectors type: Quick connect fittings3.2 Gallons NSF Standards Water Storage Tank: PRO3200PNSF Approved 3 Filter Housings (double o’ring): 3 whiteMounting bracket: Plastic type Automatic Shut-off Valve:AJ-S-3000WFlow Restrictor: 420cc AQ-FR-420Attractive design faucet: FXFCH5Feed water connector and deliver valve: FT06P, AQ-SEWBV1414-PPDrain Saddle Valve:AJ-SC500B14White Colour Coded 1/4 inch Tubing for System ConnectionAssembled &100% Factory leak tested ready for Installation
Technical FeaturesMembrane: 75 GPD / 283 LPDOperation pressure: 2.75 – 5.5 bar (40 -80 psi)Tank Pressure: 8 psiDimensions: (cm) 37 (L) x 45(H) x 20 (W) – system (cm) 28 (L) x 28(W) x 35 (H)- tank
Aquafilter AICRO 10" In-line cartridge with coconut shell granulated activated carbon (GAC). It is mostly used for RO systems in order to improve the taste and aroma of filtered water. It can also be installed in "SIDE-BY-SIDE" type refrigerators to reduce chlorine, organic substances and certain pesticides. Available with 1/4" NPT connection.
